Console server - 8 ports - 1GbE, serial
| Main Specifications | |
|---|---|
| Product Description | ATEN SN9108CO - console server |
| Device Type | Console server |
| Form Factor | External |
| Ports Qty | 8 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, serial |
| Included Accessories | Mounting kit, 4 foot pads, Lok-U-Plug, Lok-U-Plug installation tool |
| OS Required | UNIX, Linux, SunSoft Solaris, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows 2000 or later |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.2 in x 8.6 in x 1.7 in |
| Weight | 6.88 lbs |
| General | |
| Device Type | Console server |
| Width | 17.2 in |
| Depth | 8.6 in |
| Height | 1.7 in |
| Weight | 6.88 lbs |
| Expansion / Connectivity | |
| Interfaces | 8 x serial - RJ-45 ¦ 1 x 1000Base-T - RJ-45 |
| Miscellaneous | |
| Included Accessories | Mounting kit, 4 foot pads, Lok-U-Plug, Lok-U-Plug installation tool |
| Compliant Standards | RoHS, WEEE |
| Networking | |
| Form Factor | External |
| Ports Qty | 8 |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, serial |
| Network / Transport Protocol | TCP/IP, UDP/IP, NTP, SMTP, DHCP |
| Remote Management Protocol | SNMP, Telnet, HTTP, HTTPS, SSH |
| Status Indicators | Power, LAN, serial |
| Features | Auto-sensing per device, MAC address filtering, IP address filtering, Syslog support, event notification, SMS alert, SMTP e-mail client, SNMP support, SNMP trap, e-mail notification, Network Timing Protocol (NTP), IPv4 support, IPv6 support, metal housing, modem emulation |
| Encryption Algorithm | TLS 1.2, 2048-bit RSA |
| Authentication Method | Kerberos, RADIUS, TACACS+, LDAP, Active Directory |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Software / System Requirements | |
| OS Required | UNIX, Linux, SunSoft Solaris, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows 2000 or later |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% (non-condensing) |
