Expansion module - HDBaseT x 4 + RS-232 x 4 + IrDA x 4
| Main Specifications | |
|---|---|
| Product Description | Kramer DT-OUT4-F32 4-Channel 4K60 4:2:0 HDMI over Long Reach HDBaseT Output Card - expansion module - HDBaseT x 4 + RS-232 x 4 + IrDA x 4 |
| Device Type | Expansion module |
| Form Factor | Plug-in module |
| Ports | HDBaseT x 4 + RS-232 x 4 + IrDA x 4 |
| Dimensions (WxDxH) | 8.5 in x 7.5 in x 0.8 in |
| Weight | 10.58 oz |
| Data Link Protocol | HDBaseT |
| Performance | Maximum data rate: 10.2 Gbps ¦ Maximum data rate (per graphic channel): 3.4 Gbps |
| Compliant Standards | HDCP 1.4 |
| General | |
| Device Type | Expansion module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 4 x HDBaseT - RJ-45 - female ¦ 4 x RS-232 - terminal block ¦ 4 x IrDA - terminal block |
| Miscellaneous | |
| Included Accessories | Screwdriver |
| Compliant Standards | RoHS, WEEE |
| Networking | |
| Ports | HDBaseT x 4 + RS-232 x 4 + IrDA x 4 |
| Connectivity Technology | Wired |
| Data Link Protocol | HDBaseT |
| Performance | Maximum data rate: 10.2 Gbps ¦ Maximum data rate (per graphic channel): 3.4 Gbps |
| Features | 4K resolution support, HDBaseT Long Reach Mode, 12-bit Deep Color support, HDCP compliant, HDTV Compatible, 3D Pass-Through, bi-directional RS-232, bi-directional IR, Kramer Equalization & re-Klocking Technology |
| Compliant Standards | HDCP 1.4 |
| Power | |
| Power Consumption Operational | 8 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 8.5 in |
| Depth | 7.5 in |
| Height | 0.8 in |
| Weight | 10.58 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 9.8 in |
| Shipping Depth | 8.9 in |
| Shipping Height | 2.2 in |
| Shipping Weight | 17.64 oz |
