8x4 matrix switcher
| Main Specifications | |
|---|---|
| Product Description | Black Box AVSC-HDMI2-8X2 8x4 matrix switcher |
| Type | 8x4 matrix switcher |
| Dimensions (WxDxH) | 17.2 in - 14 in - 1.7 in |
| Weight | 6.61 lbs |
| Manufacturer Warranty | 2 years |
| General | |
| Type | 8x4 matrix switcher |
| Width | 17.2 in |
| Depth | 14 in |
| Height | 1.7 in |
| Weight | 6.61 lbs |
| Manufacturer Warranty | |
| Warranty | 2 years |
| Power | |
| Voltage Required | AC 120/230 V |
| Frequency | 50/60 Hz |
| Power Consumption | 85 Watt |
| Low Voltage Power | DC 24 V |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 131 °F |
| Kit Content | |
| Kit Content | (2) x rack mount brackets ¦ (1) x IR remote control ¦ (1) x IR receiver ¦ (1) x power adapter |
| Terminals | |
| Terminals | (4) x HDMI input - 19 pin HDMI Type A ¦ (1) x HDBaseT input - RJ-45 - PoC ¦ (1) x VGA input - 15 pin HD D-Sub (HD-15) ¦ (1) x DisplayPort input - 20 pin DisplayPort ¦ (1) x audio line-in - mini-phone stereo 3.5 mm ¦ (4) x balanced audio input - terminal block - stereo ¦ (1) x balanced audio output - terminal block - stereo ¦ (1) x HDBaseT output - RJ-45 ¦ (1) x HDMI output - 19 pin HDMI Type A ¦ (1) x USB - USB-C ¦ (1) x network - RJ-45 ¦ (2) x infrared input - mini-phone 3.5 mm ¦ (1) x infrared output - mini-phone 3.5 mm ¦ (1) x serial - terminal block - RS-232 ¦ (2) x relay - terminal block ¦ (2) x SPDIF output - TOSLINK |
| Studio & Production Equipment | |
| Features | EDID support, HDCP 2.2 compliant, HDR (High Dynamic Range) support, 4K60 4:4:4 600MHz 18Gbps signal support, Power Over Cable (POC) suppport |
