Document camera - color - 5 MP - 1920 x 1080 - audio - S-Video, VGA, HDMI - USB 2.0 / RS-232
| Main Specifications | |
|---|---|
| Product Description | QOMO QD3900 H1 - document camera |
| Device Type | Document camera |
| Audio | Yes: built-in microphone |
| Dimensions (WxDxH) | 20.1 in x 20.9 in x 22.4 in |
| Weight | 11.02 lbs |
| Camera | Color |
| Optical Zoom | 12 x |
| Max Resolution | 1920 x 1080 |
| Frame Rate (max) | 25 frames per second |
| Optical Sensor Type | CMOS 5 MP |
| Interfaces | USB 2.0 / serial RS-232, S-Video, VGA, HDMI |
| Control Interface | RS-232 |
| Features | Digital image rotation, digital image freeze, image mirror, negative conversion, image split, 2 LED arrays |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Document camera |
| Audio Support | Yes: built-in microphone |
| Width | 20.1 in |
| Depth | 20.9 in |
| Height | 22.4 in |
| Weight | 11.02 lbs |
| Expansion / Connectivity | |
| Ports | HDMI input ¦ HDMI output ¦ 2 x VGA input ¦ 2 x VGA output ¦ 2 x audio line in ¦ Audio line out - 3.5 mm jack ¦ USB - 4 pin USB Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 2 years |
| Miscellaneous | |
| Included Accessories | Remote control |
| Compliant Standards | Plug and Play |
| Power | |
| Power Device | Power adapter - external 12 Watt |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| Camera | |
| Type | Color |
| Max Digital Video Resolution | 1920 x 1080 |
| Digital Zoom | 10 |
| Frame Rate (max) | 25 frames per second |
| Still Image Capture Resolution | 1280 x 720, 1024 x 768, 1280 x 1024, 1920 x 1080, 1360 x 768 |
| Features | Digital image rotation, digital image freeze, image mirror, negative conversion, image split, 2 LED arrays |
| Lens Construction | |
| Optical Zoom | 12 x |
| Image Sensor | |
| Type | 5 MP CMOS |
| Interfaces | |
| Video | S-Video, VGA, HDMI |
| Computer Interface | USB 2.0 / serial RS-232 |
| Control Interface | RS-232 |
