Single LTE, FirstNet Ready - wireless router - WWAN 4-port switch - 1GbE - Wi-Fi 5 - Dual Band
| Main Specifications | |
|---|---|
| Product Description | Digi WR54 - Single LTE, FirstNet Ready - wireless router - WWAN - Wi-Fi 5 - desktop |
| Device Type | Wireless router - wireless cellular modem - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Cellular Protocol | HSPA, FDD LTE |
| Cellular Band | LTE B13, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B29, LTE B8, LTE B66, LTE B30, LTE B41, LTE B18, LTE B19, LTE B46, LTE B9, LTE B14, LTE B32, LTE B42, LTE B43, LTE B48 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 867 Mbps |
| Network / Transport Protocol | NTP, FTP, DDNS, SFTP, IPv4, IPv6 |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI, SCP, SFTP, SMTP, NTP |
| Features | Layer 2 switching, load balancing, content filtering, RADIUS support, rugged, port isolation, Captive Portal, metal housing, ToS, failover protection, 2x2 MIMO technology, cryptographic co-processor, zero-touch configuration, Digi TrustFence |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Power | DC 9 - 36 V |
| Dimensions (WxDxH) | 8.2 in x 5.8 in x 2.5 in |
| Weight | 3.31 lbs |
| Localization | Canada, United States |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 867 Mbps |
| Network / Transport Protocol | NTP, FTP, DDNS, SFTP, IPv4, IPv6 |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI, SCP, SFTP, SMTP, NTP |
| Encryption Algorithm | IKE, WPA, WPA2, WPA-Enterprise, WPA2-Enterprise, SHA-2 |
| Authentication Method | Secure Shell (SSH), RADIUS |
| Features | Layer 2 switching, load balancing, content filtering, RADIUS support, rugged, port isolation, Captive Portal, metal housing, ToS, failover protection, 2x2 MIMO technology, cryptographic co-processor, zero-touch configuration, Digi TrustFence |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, EN55024, UL 60950, CSA 22.2 No. 60950, EN55022 Class B, FCC Part 15 B, R&TTE, MIL-STD 810G, IP54, PTCRB, GCF, SAE J1113-11, SAE J1455, NAPRD.03, ISO 7637-2, EN 301 511 |
| Processor | 1 x MIPS 880 MHz |
| Built-in Devices | GPS, GLONASS, Beidou, Galileo, GNSS receiver |
| Status Indicators | Power, WAN, link/activity, GPS, Wi-Fi |
| Expansion / Connectivity | |
| Interfaces | LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Serial: 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ USB 3.0: 1 x 9 pin USB Type A ¦ Antenna: 3 x RP-SMA ¦ Antenna: 3 x SMA ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Expansion Slots | 2 (total) / 2 (free) x Mini-SIM ¦ 1 PCI Express |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Localization | Canada, United States |
| Power | |
| Power Device | External power adapter |
| Voltage Required | DC 9 - 36 V |
| Power Consumption Operational | 20 Watt |
| Software / System Requirements | |
| Software Included | Digi Remote Manager |
| Environmental Parameters | |
| Min Operating Temperature | -29.2 °F |
| Max Operating Temperature | 165.2 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Communications | |
| Type | Wireless cellular modem |
| Cellular Protocol | HSPA, FDD LTE |
| Cellular Band | LTE B13, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B29, LTE B8, LTE B66, LTE B30, LTE B41, LTE B18, LTE B19, LTE B46, LTE B9, LTE B14, LTE B32, LTE B42, LTE B43, LTE B48 |
| Max Transfer Rate | 600 Mbps |
| Dimensions & Weight | |
| Width | 8.2 in |
| Depth | 5.8 in |
| Height | 2.5 in |
| Weight | 3.31 lbs |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 6 |
