Single LTE - wireless router - WWAN 4-port switch - 1GbE - Wi-Fi 5 - Dual Band
| Main Specifications | |
|---|---|
| Product Description | Digi TransPort WR54 - Single LTE - wireless router - WWAN - Wi-Fi 5 - desktop |
| Device Type | Wireless router - wireless cellular modem - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Cellular Protocol | HSPA, FDD LTE, TDD LTE |
| Cellular Band | LTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 867 Mbps |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI, SCP, SFTP, SMTP, NTP |
| Features | Layer 2 switching, load balancing, content filtering, RADIUS support, rugged, Captive Portal, metal housing, ToS, failover protection, 2x2 MIMO technology |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Power | DC 9 - 36 V |
| Dimensions (WxDxH) | 8.2 in x 5.8 in x 2.5 in |
| Weight | 3.31 lbs |
| Localization | Worldwide |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 867 Mbps |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI, SCP, SFTP, SMTP, NTP |
| Encryption Algorithm | IKE, WPA, WPA2, WPA-Enterprise, WPA2-Enterprise, SHA-2 |
| Authentication Method | Secure Shell (SSH), RADIUS |
| Features | Layer 2 switching, load balancing, content filtering, RADIUS support, rugged, Captive Portal, metal housing, ToS, failover protection, 2x2 MIMO technology |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, EN55024, UL 60950, CSA 22.2 No. 60950, EN55022 Class B, FCC Part 15 B, R&TTE, MIL-STD 810G, IP54, PTCRB, GCF, SAE J1113-11, SAE J1455, NAPRD.03, ISO 7637-2, EN 301 511 |
| Processor | 1 x MIPS 880 MHz |
| RAM | 256 MB |
| Flash Memory | 512 MB |
| Built-in Devices | GPS, GLONASS, Beidou, Galileo, GNSS receiver |
| Status Indicators | Power, WAN, wireless, GPS, Wi-Fi |
| Expansion / Connectivity | |
| Interfaces | WAN / LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Antenna: 3 x SMA ¦ Antenna: 2 x RP-SMA ¦ USB 3.0: 1 x 9 pin USB Type A ¦ Serial: 1 x RS-232 - 9 pin D-Sub (DB-9) |
| Expansion Slots | 2 (total) / 2 (free) x Mini-SIM |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Localization | Worldwide |
| Power | |
| Voltage Required | DC 9 - 36 V |
| Power Consumption Operational | 20 watt |
| Software / System Requirements | |
| Software Included | Digi Remote Manager |
| Environmental Parameters | |
| Min Operating Temperature | -29.2 °F |
| Max Operating Temperature | 165.2 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Communications | |
| Type | Wireless cellular modem |
| Cellular Protocol | HSPA, FDD LTE, TDD LTE |
| Cellular Band | LTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38 |
| Max Transfer Rate | 600 Mbps |
| Dimensions & Weight | |
| Width | 8.2 in |
| Depth | 5.8 in |
| Height | 2.5 in |
| Weight | 3.31 lbs |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 2 |
