All-in-one - Core i5 6300U up to - RAM 4 GB - no HDD - Gigabit Ethernet - no OS - monitor: LCD 15.6" 1366 x 768 (HD) touchscreen - white
| Main Specifications | |
|---|---|
| Product Description | Advantech Ubiquitous Touch Computer UTC-315F - all-in-one - Core i5 6300U 2.4 GHz - 4 GB - no HDD - LCD 15.6" |
| Type | Personal computer - all-in-one |
| Processor | Intel Core i5 (6th Gen) 6300U / 2.4 GHz (Dual-Core) |
| Cache Memory | 3 MB L3 cache |
| Cache Per Processor | 3 MB |
| RAM | 4 GB (installed) / 16 GB (max) - DDR4 SDRAM |
| Storage Controller | SATA |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Monitor | 15.6" - LCD - 1366 x 768 (HD) - 16:9 - touchscreen |
| Audio Output | Stereo |
| Networking | 1GbE |
| OS Provided | No operating system |
| Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Dimensions (WxDxH) | 15.8 in x 1.6 in x 10.2 in |
| Weight | 8.82 lbs |
| General | |
| Type | Personal computer |
| Product Form Factor | All-in-one |
| Built-in Devices | Stereo speakers |
| Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Expansion / Connectivity | |
| Bays | 1 internal 2.5" |
| Slots | 1 Mini PCIe/mSATA (full-size) |
| Interfaces | 2 x LAN (Gigabit Ethernet) ¦ 2 x serial ¦ 2 x USB 2.0 ¦ 1 x HDMI ¦ 4 x USB 3.0 ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack |
| Miscellaneous | |
| VESA Mounting Interface | 75 x 75 mm |
| Compliant Standards | UL, BSMI, CB, CCC, FCC, RoHS, NEMA Type 4, IP65 |
| RAM | |
| Installed Size | 4 GB / 16 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 2133 MHz |
| Rated Memory Speed | 2133 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 1 (total) |
| Configuration Features | 1 x 4 GB |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL) |
| Power | |
| Device Type | Power adapter |
| Power Consumption Operational | 32 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Storage Controller | |
| Type | SATA |
| Cache Memory | |
| Installed Size | L3 cache - 3 MB |
| Cache Per Processor | 3 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | LCD |
| Touchscreen | Yes |
| Diagonal Size | 15.6" |
| Native Resolution | 1366 x 768 (HD) |
| Widescreen Display | Yes |
| Image Aspect Ratio | 16:9 |
| Horizontal Viewing Angle | 90 |
| Vertical Viewing Angle | 60 |
| Pixel Pitch | 0.252 mm |
| Image Brightness | 200 cd/m² |
| Monitor Features | Projected Capacitive Touch (P-CAP) technology |
| Graphics Controller | |
| Video Interfaces | HDMI |
| Audio Output | |
| Sound Output Mode | Stereo |
| Speakers Included | 2 x right / left channel |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 15.8 in |
| Depth | 1.6 in |
| Height | 10.2 in |
| Weight | 8.82 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (6th Gen) 6300U |
| Clock Speed | 2.4 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
