All-in-one - Core i5 6300U up to - RAM 4 GB - no HDD - HD Graphics 520 - Gigabit Ethernet - no OS - monitor: LED 42.5" 1920 x 1080 (Full HD) touchscreen
| Main Specifications | |
|---|---|
| Product Description | Advantech Ubiquitous Touch Computer UTC-542F - all-in-one - Core i5 6300U 2.4 GHz - 4 GB - no HDD - LED 42.5" |
| Type | Personal computer - all-in-one |
| Processor | Intel Core i5 (6th Gen) 6300U / 2.4 GHz (Dual-Core) |
| Cache Memory | 3 MB L3 cache |
| Cache Per Processor | 3 MB |
| RAM | 4 GB (installed) / 16 GB (max) - DDR3L SDRAM |
| Storage Controller | RAID |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Monitor | 42.5" - LED - 1920 x 1080 (Full HD) - touchscreen |
| Graphics Controller | Intel HD Graphics 520 |
| Audio Output | Stereo |
| Networking | 1GbE |
| Power | AC 120/230 V (50/60 Hz) |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 40 in x 2.4 in x 23.8 in |
| Weight | 54.23 lbs |
| General | |
| Type | Personal computer |
| Product Form Factor | All-in-one |
| Built-in Devices | Stereo speakers |
| Expansion / Connectivity | |
| Bays | 2 (total) / 2 (free) x hot-swap 2.5" |
| Slots | 1 (total) / 1 (free) x Mini PCIe/mSATA |
| Interfaces | 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 2 x serial - DB-9 ¦ 3 x USB 2.0 - Type A ¦ 2 x USB 3.0 - Type A ¦ 1 x HDMI ¦ 1 x VGA ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack |
| Miscellaneous | |
| VESA Mounting Interface | 200 x 200 mm |
| Compliant Standards | UL, CCC, FCC, RoHS, NEMA Type 4, IP65, Directive 2002/95/EC |
| RAM | |
| Installed Size | 4 GB / 16 GB (max) |
| Technology | DDR3L SDRAM |
| Effective Memory Speed | 1600 MHz |
| Form Factor | SO-DIMM 204-pin |
| Slots | 2 (total) |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Storage Controller | |
| Type | RAID |
| RAID Level | RAID 0, RAID 1 |
| Cache Memory | |
| Installed Size | L3 cache - 3 MB |
| Cache Per Processor | 3 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | LED |
| Touchscreen | Yes |
| Diagonal Size | 42.5" |
| Native Resolution | 1920 x 1080 (Full HD) |
| Widescreen Display | Yes |
| Horizontal Viewing Angle | 178 |
| Vertical Viewing Angle | 178 |
| Pixel Pitch | 0.49 mm |
| Image Brightness | 450 cd/m² |
| Monitor Features | Projected Capacitive Touch (P-CAP) technology, mirror coating |
| Graphics Controller | |
| Graphics Processor | Intel HD Graphics 520 |
| Video Interfaces | VGA, HDMI |
| Audio Output | |
| Sound Output Mode | Stereo |
| Speakers Included | 2 x right / left channel |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 40 in |
| Depth | 2.4 in |
| Height | 23.8 in |
| Weight | 54.23 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (6th Gen) 6300U |
| Clock Speed | 2.4 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
