Switch - managed - 48 x 1 Gigabit / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ - front to back airflow - rack-mountable
The QuantaMesh T3048-LY2R supports 48 SFP+ and 4 QSFP+ ports in a compact 1U size. Leveraging merchant silicon chips, the T3048-LY2R is a high-performance, high-density Ethernet switch with an affordable cost for the deployment of data center infrastructure.
| Main Specifications | |
|---|---|
| Product Description | QCT QuantaMesh BMS T3048-LY2R - switch - 48 ports - managed - rack-mountable |
| Device Type | Switch - 48 ports - managed |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Subtype | 40 Gigabit Ethernet |
| Ports | 48 x 1 Gigabit / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ |
| Performance | Switching capacity: 1.28 Tbps ¦ Forwarding performance: 952 Mpps ¦ Latency: 1 µs |
| MAC Address Table Size | 128K entries |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.1 in x 15.5 in x 1.7 in |
| Weight | 17.26 lbs |
