Power amplifier - 2 x 30 Watt
| Main Specifications | |
|---|---|
| Product Description | Yamaha PA2030a - power amplifier |
| Product Type | Power amplifier |
| Audio Specifications | Amplifier - 50 - 20000 Hz 0.1% |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 8.5 in x 11.3 in x 2.1 in |
| Weight | 3.97 lbs |
| General | |
| Product Type | Power amplifier |
| Power | |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 30 Watt |
| Connections | |
| Connectors | Audio line-in (RCA x 2) - rear ¦ 2 x balanced audio input (terminal block) - rear ¦ 2 x speakers output (screw-type) - rear |
| Dimensions & Weight | |
| Width | 8.5 in |
| Depth | 11.3 in |
| Height | 2.1 in |
| Weight | 3.97 lbs |
| Audio System | |
| Functions | Amplifier |
| Amplifier Class | D |
| Audio Specifications | Amplifier - Response Bandwidth - 50 - 20000 Hz - THD - 0.1% |
| Output Channel Qty | 2 channels |
| Output Power (per channel) | 30 Watt |
| Amplifier Output Details | 30 Watt - 3 Ohm - at 1 kHz - THD 1% - 2 channels ¦ 30 Watt - 4 Ohm - at 1 kHz - THD 1% - 2 channels ¦ 30 Watt - 8 Ohm - at 1 kHz - THD 1% - 2 channels ¦ 60 Watt - 1 channels (70/100V) |
| Features | Thermal protection, DC protection, over current protection, over voltage protection, audio limiters protection, 70V/100V operation, on/off transient protection |
