Server - rack-mountable - 2U - 2-way - 2 x Xeon E5-2620 / 2 GHz - RAM 16 GB - SAS - hot-swap 3.5" bay(s) - no HDD - G200e - Gigabit Ethernet - monitor: none - remanufactured
| Main Specifications | |
|---|---|
| Product Description | Cisco Connected Safety and Security UCS C240 - rack-mountable - Xeon E5-2620 2 GHz - 16 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 2U |
| Server Scalability | 2-way |
| Processor | 2 x Intel Xeon E5-2620 / 2 GHz (, up to 2.5 GHz, (6-core) |
| Processor Socket | LGA2011 Socket |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| Cache Memory | 30 MB L3 cache |
| Cache Per Processor | 15 MB |
| RAM | 16 GB (installed) / 768 GB (max) - DDR3 SDRAM - Advanced ECC |
| Storage Controller | RAID (SATA 6Gb/s / SAS 6Gb/s) - PCIe 2.0 x8 (LSI MegaRAID SAS 9271CV-8i) |
| Server Storage Bays | Hot-swap 3.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | Matrox G200e |
| Video Memory | 256 MB |
| Networking | 1GbE |
| Power | AC 120/230 V (50/60 Hz) |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 17.5 in x 28 in x 3.4 in |
| Pricing Type | Remanufactured |
| Manufacturer Warranty | Limited warranty - replacement - 1 year - response time: 10 days |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 2U |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 12 |
| Expansion / Connectivity | |
| Bays | 12 (total) / 12 (free) x hot-swap 3.5" |
| Slots | 2 (total) / 2 (free) x PCIe 3.0 x24 - three-quarter-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, low-profile (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x8 mode) |
| Interfaces | 1 x serial ¦ 2 x USB 2.0 ¦ 1 x management (NIC) ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x KVM (1 in front) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - 1 year - response time: 10 days |
| Miscellaneous | |
| Compliant Standards | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, GB 4943, EN 300 386 |
| Pricing Type | Remanufactured |
| RAM | |
| Installed Size | 16 GB / 768 GB (max) |
| Technology | DDR3 SDRAM - Advanced ECC |
| Form Factor | DIMM 240-pin |
| Slots | 24 (total) / 22 (empty) |
| Features | Registered, dual rank, low-voltage |
| Configuration Features | 2 x 8 GB |
| Networking | |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | Intel I350 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0, CLI |
| Remote Management Controller | Emulex Pilot 3 iBMC |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 650 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x RAID - PCIe 2.0 x8 |
| Controller Interface Type | SATA 6Gb/s / SAS 6Gb/s |
| Storage Controller Name | LSI MegaRAID SAS 9271CV-8i |
| Channel Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| Buffer Size | 1 GB |
| Cache Memory | |
| Installed Size | L3 cache - 30 MB |
| Cache Per Processor | 15 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Matrox G200e |
| Video Memory | 256 MB |
| Video Interfaces | VGA |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.5 in |
| Depth | 28 in |
| Height | 3.4 in |
| Processor / Chipset | |
| CPU | Intel Xeon E5-2620 |
| Clock Speed | 2 GHz |
| Max Turbo Speed | 2.5 GHz |
| Number of Cores | 6-core |
| CPU Qty | 2 |
| Max CPU Qty | 2 |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| CPU Socket | LGA2011 Socket |
| Chipset Type | Intel C600 |
