SFP+ transceiver module - LC single-mode - up to 20.5 miles - 1310 nm
| Main Specifications | |
|---|---|
| Product Description | Kramer OSP-SM10 - SFP+ transceiver module |
| Device Type | SFP+ transceiver module - LC single-mode |
| Form Factor | Plug-in module |
| Data Transfer Rate | 10.2 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 20.5 miles |
| General | |
| Device Type | SFP+ transceiver module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 1 x - LC single-mode female x 2 |
| Miscellaneous | |
| Compliant Standards | UL, cUL, EN55022, EN55024, Laser Class 1, RoHS, FDA, MSA SFF-8431, EN60950-2:2007 |
| Networking | |
| Connectivity Technology | Wired |
| Data Transfer Rate | 10.2 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 20.5 miles |
| Compliant Standards | IEEE 802.3ae |
| Power | |
| Power Consumption Operational | 1 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 95% |
