Server - blade 2-way - 2 x Xeon E5-2640V4 / up to 3.4 GHz - RAM 64 GB - SAS - hot-swap 2.5" bay(s) - no HDD - G200eH - Gigabit Ethernet, 10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE) - monitor: none
| Main Specifications | |
|---|---|
| Product Description | HPE ProLiant BL460c Gen9 - blade Xeon E5-2640V4 2.4 GHz - 64 GB - no HDD |
| Type | Server - blade |
| Localization | Region: United States |
| Server Scalability | 2-way |
| Processor | 2 x Intel Xeon E5-2640V4 / 2.4 GHz (up to 3.4 GHz, (10-core) |
| Processor Socket | FCLGA2011-v3 Socket |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cache Memory | 50 MB L3 cache |
| Cache Per Processor | 25 MB |
| RAM | 64 GB (installed) / 512 GB (max) - DDR4 SDRAM - Advanced ECC - PC4-19200 |
| Storage Controller | SAS-3 (SATA 6Gb/s / SAS 12Gb/s) - PCIe 3.0 x8 (HP H244br Smart Host Bus Adapter) |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | Matrox G200eH |
| Networking | 1GbE, 10GbE, FCoE |
| Dimensions (WxDxH) | 2.2 in x 20.4 in x 7.1 in |
| Weight | 10.47 lbs |
| Manufacturer Warranty | Limited warranty - parts and labor - 3 years - on-site |
| General | |
| Type | Server |
| Product Form Factor | Blade |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 2 |
| Localization | Region: United States |
| Expansion / Connectivity | |
| Bays | 2 (total) / 2 (free) x hot-swap 2.5" SFF |
| Slots | 2 expansion slot (x16 mode) ¦ 1 (total) / 1 (free) x microSDHC Card (internal) ¦ 1 (total) / 0 (free) x FlexibleLOM |
| Interfaces | 1 x HPE iLO ¦ 1 x USB 3.0 (1 internal) ¦ 2 x LAN (10Gigabit Ethernet) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site |
| Miscellaneous | |
| Compliant Standards | ACPI 2.0, FIPS 140-2 Level 2, AES, Triple DES, ASHRAE |
| RAM | |
| Installed Size | 64 GB (installed) / 512 GB (max) |
| Technology | DDR4 SDRAM - Advanced ECC |
| Effective Memory Speed | 2133 MHz |
| Rated Memory Speed | 2400 MHz |
| Memory Specification Compliance | PC4-19200 |
| Form Factor | DIMM 288-pin |
| Slots | 16 (total) / 12 (empty) |
| Features | Registered, Online Spare Memory, HP SmartMemory |
| Configuration Features | 4 x 16 GB |
| RAM Supported | 512 GB registered - Advanced ECC ¦ 2 TB Load-Reduced - Advanced ECC |
| Networking | |
| Interface (Bus) Type | FlexibleLOM |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Ethernet Controller | HP FlexFabric 536FLB |
| Data Link Protocol | Gigabit Ethernet, 10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE) |
| Remote Management Protocol | SNMP, IPMI 2.0, SMASH CLP |
| Remote Management Controller | Integrated Lights-Out 4 |
| Features | Wake on LAN (WoL) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.1Qau |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x SAS-3 - PCIe 3.0 x8 |
| Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| Storage Controller Name | HP H244br Smart Host Bus Adapter |
| RAID Level | RAID 0, RAID 1 |
| Cache Memory | |
| Installed Size | L3 cache - 50 MB |
| Cache Per Processor | 25 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Matrox G200eH |
| Operating System / Software | |
| OS Certified | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Canonical Ubuntu |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 2.2 in |
| Depth | 20.4 in |
| Height | 7.1 in |
| Weight | 10.47 lbs |
| Processor / Chipset | |
| CPU | Intel Xeon E5-2640V4 |
| Clock Speed | 2.4 GHz |
| Max Turbo Speed | 3.4 GHz |
| Number of Cores | 10-core |
| CPU Qty | 2 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| CPU Socket | FCLGA2011-v3 Socket |
