USB Type-C Gigabit Network Adapter (US1GC301AU2R) - Network adapter - USB-C - Gigabit Ethernet x 2 + USB 3.0 - for P/N: TB33A1C
| Main Specifications | |
|---|---|
| Product Description | Startech USB-C to Dual Gigabit Ethernet Adapter with USB 3.0 (Type-A) Port - USB Type-C Gigabit Network Adapter (US1GC301AU2R) - network adapter - USB-C - Gigabit Ethernet x 2 + USB 3.0 |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C |
| Ports | Gigabit Ethernet x 2 + USB 3.0 |
| Dimensions (WxDxH) | 2.4 in x 3 in x 0.6 in |
| Weight | 2.08 oz |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Data Transfer Rate | 1 Gbps |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az |
| System Requirements | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Linux Kernel 2.6.25 or later, Microsoft Windows Server 2019, Linux LTS versions only, Apple MacOS X 10.6 - 10.15, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Apple macOS 11.3 or later |
| Manufacturer Warranty | 2-year warranty |
| Designed For | P/N: TB33A1C |
| General | |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T - RJ-45 - female ¦ 1 x USB 3.0 - 9 pin USB Type A - female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x SuperSpeed USB-C cable (integrated) |
| Compliant Standards | FCC, RoHS |
| Networking | |
| Ports | Gigabit Ethernet x 2 + USB 3.0 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Status Indicators | Link/activity |
| Features | Full duplex capability, auto-uplink (auto MDI/MDI-X), USB powered, Energy Efficient Ethernet, 4K resolution support, USB Pass-Through, VLAN Tagging (not supported in MacOS) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Linux Kernel 2.6.25 or later, Microsoft Windows Server 2019, Linux LTS versions only, Apple MacOS X 10.6 - 10.15, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Apple macOS 11.3 or later |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 20 - 80% |
| Dimensions & Weight | |
| Width | 2.4 in |
| Depth | 3 in |
| Height | 0.6 in |
| Weight | 2.08 oz |
| Compatibility Information | |
| Designed For | P/N: TB33A1C |
