Unified storage system - 12 bays - rack-mountable - SAS 12Gb/s - RAID 0, 1, 3, 5, 6, 10, 30, 50, 60 - RAM 32 GB - Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 2U
| Main Specifications | |
|---|---|
| Product Description | Infortrend EonStor GS 3000 Series GS 3012 Gen1 - unified storage system |
| Device Type | Unified storage system |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 2U |
| Installed Devices / Modules Qty | 0 (installed) / 12 (max) |
| Dimensions (WxDxH) | 17.7 in x 19.7 in x 3.5 in |
| Weight | 31.97 lbs () |
| Processor | Intel Xeon |
| Storage Controller | 2 x RAID SAS 12Gb/s RAID 0, 1, 3, 5, 6, 10, 30, 50, 60 |
| Networking | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| RAM | 32 GB |
| Power | AC 100-240 V (47 - 63 Hz) |
| Power Redundancy | Yes |
| System Requirements | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows 7 SP1, Windows 8.1, Microsoft Windows Hyper-V Server, Red Hat Enterprise Linux, SUSE Linux Enterprise, Oracle Solaris, Apple MacOS X, Citrix XenServer |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Unified storage system |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 2U |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 12 (max) |
| Width | 17.7 in |
| Depth | 19.7 in |
| Height | 3.5 in |
| Weight | 31.97 lbs () |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots | 4 (total) / 4 (free) x expansion slot |
| Interfaces | 4 x Ethernet 1000Base-T - RJ-45 ¦ 4 x Ethernet 10Gb - RJ-45 ¦ 4 x SAS 12Gb/s ¦ Management |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years ¦ Limited warranty - battery - 2 years ¦ Technical support - phone consulting - 3 years ¦ Product info support - web support - 3 years ¦ Product info support - e-mail consulting - 3 years |
| Miscellaneous | |
| Features | Flash backup module, super capacitor battery, built-in 2 cooling fans, Self-Encrypting Drive (SED) support |
| Compliant Standards | UL, BSMI, CB, FCC |
| Included Accessories | Rack mounting kit |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| Network / Transport Protocol | FTP, NFS, SMB, iSCSI |
| Remote Management Protocol | SNMP |
| Network Services Compatibility | Microsoft CIFS, FTP, Server Message Block 3.0 (SMB 3.0), Server Message Block 2.0 (SMB 2.0), Network File System v2 (NFS v2), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Apple File Protocol v2.2.2 (AFP v2.2.2), Web-based Distributed Authoring and Versioning (WebDAV), Microsoft Active Directory (AD) |
| Features | Cloud backup, LDAP support, Syslog support, VPN Server, FXP support, WORM protection, anti-virus protection, SNMP trap, e-mail notification, proxy server, OpenStack compatible, Baidu cloud support, Microsoft Azure support, Amazon S3 support, Alibaba Cloud OSS support, Google Drive support, Tencent COS support, trunking |
| Encryption Algorithm | 256-bit AES, SSL |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 100-240 V (47 - 63 Hz) |
| Power Provided | 530 watt |
| 80 PLUS Certification | 80 PLUS Bronze |
| Power Factor Correction | Yes |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows 7 SP1, Windows 8.1, Microsoft Windows Hyper-V Server, Red Hat Enterprise Linux, SUSE Linux Enterprise, Oracle Solaris, Apple MacOS X, Citrix XenServer |
| Storage Controller | |
| Type | 2 x RAID |
| Interface Type | SAS 12Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10, RAID 30, RAID 50, RAID 60 |
| Processor / Memory | |
| Processors Installed | Intel Xeon |
| RAM | 32 GB (installed) / 256 GB (supported) - DDR4 |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 30.7 in |
| Shipping Depth | 23.1 in |
| Shipping Height | 14.9 in |
