Monitor terminal expansion module - DVI - 100Mb LAN, HDBaseT - 17 Watt
| Main Specifications | |
|---|---|
| Product Description | Samsung Signage Meeting Box SBB-MT12EA - monitor terminal expansion module - DVI - 100Mb LAN, HDBaseT |
| Product Type | Monitor terminal expansion module |
| Video Interfaces | DVI |
| Dimensions (WxDxH) | 8.8 in x 5.5 in x 1.3 in |
| Weight | 24.69 oz |
| Networking | Fast Ethernet, HDBaseT |
| Power | Power adapter AC 120/230 V (50/60 Hz) 17 watt Power Provided |
| General | |
| Product Type | Monitor terminal expansion module |
| Width | 8.8 in |
| Depth | 5.5 in |
| Height | 1.3 in |
| Weight | 24.69 oz |
| Expansion / Connectivity | |
| Interfaces | HDBaseT ¦ Network - RJ-45 ¦ 1 x USB - 4 pin USB Type A ¦ 2 x display / video - HDMI input - 19 pin HDMI Type A ¦ Display / video - DVI-Analog/Digital output - 24+5 pin combined DVI ¦ Remote control ¦ Serial |
| Miscellaneous | |
| Cables Included | HDMI-DVI cable |
| Included Accessories | IR sensor, Meeting Console |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, HDBaseT |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 17 watt |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 104 °F |
