Thunderbolt adapter - PCIe 3.0 x4 - Thunderbolt 3 / USB-C 3.1 x 1 + USB 3.1 x 1
| Main Specifications | |
|---|---|
| Product Description | ASUS ThunderboltEX 3 - Thunderbolt adapter - PCIe 3.0 x4 - Thunderbolt 3 / USB-C 3.1 x 1 + USB 3.1 x 1 |
| Device Type | Thunderbolt adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 3.0 x4 |
| Ports | Thunderbolt 3 / USB-C 3.1 x 1 + USB 3.1 x 1 |
| Dimensions (WxDxH) | 3.3 in x 3.9 in |
| Cabling Type | Thunderbolt 3 |
| Data Link Protocol | USB 3.1 |
| System Requirements | Microsoft Windows 7 (32/64 bits), Windows 8 64-bit Edition, Windows 8.1 64-bit Edition, Windows 10 |
| General | |
| Device Type | Thunderbolt adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 3.0 x4 |
| Expansion / Connectivity | |
| Interfaces | 1 x Thunderbolt 3 - 24 pin USB-C ¦ 1 x DisplayPort input - Mini DisplayPort ¦ 1 x Thunderbolt - 9 pin Thunderbolt header ¦ 1 x USB 3.1 |
| Miscellaneous | |
| Cables Included | 1 x Mini DisplayPort cable ¦ 1 x Thunderbolt header cable |
| Networking | |
| Ports | Thunderbolt 3 / USB-C 3.1 x 1 + USB 3.1 x 1 |
| Cabling Type | Thunderbolt 3 |
| Data Link Protocol | USB 3.1 |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows 7 (32/64 bits), Windows 8 64-bit Edition, Windows 8.1 64-bit Edition, Windows 10 |
| Dimensions & Weight | |
| Depth | 3.3 in |
| Height | 3.9 in |
