Fiber media converter - 100Mb LAN - 10Base-T, 100Base-FX, 100Base-TX - RJ-45 / ST multi-mode
| Main Specifications | |
|---|---|
| Product Description | ComNet CNFE1002APOEMHO/M - fiber media converter - 10Mb LAN, 100Mb LAN |
| Device Type | Fiber media converter - RJ-45 / ST multi-mode |
| Form Factor | External |
| Cabling Type | 10Base-T, 100Base-FX, 100Base-TX |
| Data Transfer Rate | 100 Mbps |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Power Over Ethernet (PoE) | PoE+ |
| Power | DC 48 V |
| Dimensions (WxDxH) | 3.7 in x 4.1 in x 1.1 in |
| Weight | 17.64 oz |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Fiber media converter |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10Base-T/100Base-TX - RJ-45 female ¦ 1 x Ethernet 100Base-FX - ST multi-mode female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| MTBF | 100,000 hours |
| Compliant Standards | Plug and Play, cULus, RoHS |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-FX, 100Base-TX |
| Data Link Protocol | 10Mb LAN, 100Mb LAN |
| Data Transfer Rate | 100 Mbps |
| Status Indicators | Power, link/activity, PoE |
| Features | Auto-negotiation, half duplex mode, full duplex mode |
| Compliant Standards | IEEE 802.3at, IEEE 802.3 |
| Power | |
| Power Over Ethernet (PoE) | PoE+ |
| Voltage Required | DC 48 V |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 167 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 3.7 in |
| Depth | 4.1 in |
| Height | 1.1 in |
| Weight | 17.64 oz |
