Network surveillance camera - dome - vandal / weatherproof - color (Day&Night) - 12 MP - 4000 x 3072 - M12 mount - fixed focal - audio - GbE - MJPEG, H.264 - DC 12 V / PoE
| Main Specifications | |
|---|---|
| Product Description | Hikvision Smart IPC DS-2CD63C2F-IV - network surveillance camera - dome |
| Device Type | Network surveillance camera - fixed - dome - vandal / weatherproof |
| Audio | Yes: built-in speaker, two-way audio capability, built-in microphone |
| Camera Mount Type | Surface mount, wall mount, ceiling mount |
| Dimensions (WxDxH) | 6.5 in x 6 in x 1.7 in |
| Weight | 3.09 lbs |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night - NTSC, PAL |
| Max Resolution | 4000 x 3072 |
| Frame Rate (max) | 25 frames per second |
| Motion Detection | Yes |
| Optical Sensor Type | CMOS - 1/1.7" - 12 MP |
| Minimum Illumination | 0.01 lux F1.2 ¦ 0.04 lux F2.4 ¦ 0 lux - IR |
| Focal Length Control | Fixed focal |
| Focal Length | 1.98 mm |
| Lens Mounting | M12 mount |
| Lens Iris | F/2.4 |
| Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Voltage | DC 12 V / PoE |
| Features | Sharpness control, white balance, progressive scanning, saturation control, brightness control, contrast control, ONVIF support, 3D Noise Reduction Technology, Motion Detection Technology, infrared cut filter, Digital Wide Dynamic Range (D-WDR), hue control, PSIA, NAS-Ready, dual video stream, active tampering alarm, fisheye lens, Region of Interest (ROI), intrusion detection, auto gain control |
| Environmental Parameters (operating) | -22 °F - 140 °F; 0 - 95% (non-condensing) relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Audio Support | Yes: built-in speaker, two-way audio capability, built-in microphone |
| Form Factor | Dome |
| Camera Mount Type | Surface mount, wall mount, ceiling mount |
| Connectivity Technology | Wired |
| Width | 6.5 in |
| Depth | 6 in |
| Height | 1.7 in |
| Weight | 3.09 lbs |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | |
| Compliant Standards | IEC 60068-2-75, IK10, IP66, EN 50102 |
| Power | |
| Power Requirements | DC 12 V / PoE |
| Power Device | 12 watt |
| Environmental Parameters | |
| Min Operating Temperature | -22 °F |
| Max Operating Temperature | 140 °F |
| Relative Humidity (operating) | 0 - 95% (non-condensing) |
| Camera | |
| Type | Color - Day&Night - fixed - vandal / weatherproof |
| Video Format | NTSC, PAL |
| Digital Video Format | MJPEG, H.264 |
| Max Digital Video Resolution | 4000 x 3072 |
| Motion Detection | Yes |
| Exposure Range | 1/25 sec - 1/100000 sec |
| Minimum Illumination | 0.01 lux F1.2 ¦ 0.04 lux F2.4 ¦ 0 lux - IR |
| Infrared LEDs | Yes |
| Infrared Distance | 49 ft |
| Digital Video Capture Resolution | 1600 x 1200, 704 x 576, 3072 x 2304, 1280 x 1280, 2048 x 2048, 4000 x 3072, 3072 x 3072, 2560 x 2560, 720 x 720, 3072 x 1152 |
| Frame Rate (max) | 25 frames per second |
| Features | Sharpness control, white balance, progressive scanning, saturation control, brightness control, contrast control, ONVIF support, 3D Noise Reduction Technology, Motion Detection Technology, infrared cut filter, Digital Wide Dynamic Range (D-WDR), hue control, PSIA, NAS-Ready, dual video stream, active tampering alarm, fisheye lens, Region of Interest (ROI), intrusion detection, auto gain control |
| Lens Construction | |
| Type | M12 mount - fixed focal |
| Focal Length | 1.98 mm |
| Lens Iris | F/2.4 |
| Horizontal Field of View (degree) | 360 |
| Image Sensor | |
| Type | 12 MP CMOS 1/1.7" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, IPv6, Bonjour, RTCP, PPPoE, IGMP, QOS, PSIA |
