Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | TP-Link Omada EAP330 - wireless access point - Wi-Fi 5 |
| Device Type | Wireless access point |
| Form Factor | External |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz, 5 GHz |
| Included Accessories | Wall mounting kit, ceiling mounting kit |
| OS Required | Microsoft Windows Vista / XP / 7 / 8, Windows 10 |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 8.7 in x 7.6 in x 1.4 in |
| General | |
| Device Type | Wireless access point |
| Width | 8.7 in |
| Depth | 7.6 in |
| Height | 1.4 in |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Included Accessories | Wall mounting kit, ceiling mounting kit |
| Compliant Standards | UL 2043, FCC, RoHS |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1900 Mbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 2c, HTTP, HTTPS |
| Frequency Band | 2.4 GHz, 5 GHz |
| Features | Load balancing, VLAN support, E-mail alert, MAC address filtering, MIMO technology, wall mountable, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Multiple SSID support, reset button, ceiling mountable, Captive Portal, security lock slot (cable lock sold separately), Broadcom TurboQAM technology, Watch Dog Timer (WDT), beamforming technology, band steering, rate limit, Wireless Scheduler |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, 152-bit WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise |
| Authentication Method | RADIUS |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Device | External power adapter |
| Power Consumption Operational | 14 watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows Vista / XP / 7 / 8, Windows 10 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Antenna | |
| Antenna | Internal |
| Directivity | Omni-directional |
