Power distribution unit (rack-mountable) - AC 100-240 V - 5000 Watt - 2300 VA - Ethernet 10/100 - input: IEC 60320 C14 - output connectors: 8 (power IEC 60320 C13) - 1U
| Main Specifications | |
|---|---|
| Product Description | ATEN PE7108G - power distribution unit - 5000 Watt - 2300 VA |
| Device Type | Power distribution unit - rack-mountable |
| Rack Size | 1U |
| Weight | 6.33 lbs |
| Input Voltage | AC 100-240 V |
| Output Voltage | AC 100-240 V |
| Power Capacity | 5000 Watt / 2300 VA |
| Input Connectors | 1 x power IEC 60320 C14 |
| Output connectors | 8 x power IEC 60320 C13 |
| Networking | Ethernet 10/100 |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS |
| Dimensions (WxDxH) | 1.7 in x 8.6 in x 17 in |
| General | |
| Device Type | Power distribution unit - rack-mountable |
| Height (Rack Units) | 1U |
| Expansion / Connectivity | |
| Interfaces | 1 x LAN ¦ 2 x monitoring - RJ-11 |
| Miscellaneous | |
| Cables Included | Power cable - external - 10 ft |
| Rack Mounting Kit | Included |
| Compliant Standards | RoHS |
| Networking | |
| Remote Management Interface | Ethernet 10/100 |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power IEC 60320 C14 |
| Power Output Connectors Details | 8 x power IEC 60320 C13 |
| Output Voltage | AC 100-240 V |
| Max Electric Current | 10 A |
| Power Capacity | 5000 Watt / 2300 VA |
| Dimensions & Weight | |
| Width | 1.7 in |
| Depth | 8.6 in |
| Height | 17 in |
| Weight | 6.33 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 5.5 in |
| Shipping Depth | 12.2 in |
| Shipping Height | 20.9 in |
| Shipping Weight | 12.79 lbs |
