Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | D-Link DWL-8710AP - wireless access point - Wi-Fi 5 |
| Device Type | Wireless access point |
| Form Factor | External - outdoor |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz, 5 GHz |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 8.7 in x 1.8 in x 9.8 in |
| Weight | 4.53 lbs |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Outdoor |
| Width | 8.7 in |
| Depth | 1.8 in |
| Height | 9.8 in |
| Weight | 4.53 lbs |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Compliant Standards | UL, VCCI, C-Tick, cUL, CB, CCC, FCC, TELEC, IP67, NCC, EN 300 328, EN 301 893 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1200 Mbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Remote Management Protocol | SNMP, Telnet, HTTP, HTTPS, SSH, CLI |
| Frequency Band | 2.4 GHz, 5 GHz |
| Status Indicators | Power, WLAN, LAN |
| Features | Load balancing, VLAN support, Wireless Distribution System (WDS) support, Spanning Tree Protocol (STP) support, Wireless Intrusion Detection System (WIDS), Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Multiple SSID support, 2T2R MIMO technology, SNMP support |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, 152-bit WEP, WPA, WPA2, WPA-Enterprise, WPA2-Enterprise, WEP |
| Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3x, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Consumption Operational | 16.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 4 |
| Directivity | Omni-directional |
