Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | TP-Link Omada EAP320 - wireless access point - Wi-Fi 5 |
| Device Type | Wireless access point |
| Form Factor | External |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz, 5 GHz |
| OS Required | Microsoft Windows Vista / XP / 7 / 8, Windows 10 |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 8.7 in x 7.6 in x 1.4 in |
| General | |
| Device Type | Wireless access point |
| Width | 8.7 in |
| Depth | 7.6 in |
| Height | 1.4 in |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Compliant Standards | UL 2043, FCC, RoHS |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1167 Mbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 2c, HTTP, HTTPS, CLI |
| Frequency Band | 2.4 GHz, 5 GHz |
| Features | Load balancing, VLAN support, Syslog support, manageable, E-mail alert, MAC address filtering, MIMO technology, wall mountable, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Multiple SSID support, ceiling mountable, security lock slot (cable lock sold separately), Broadcom TurboQAM technology, Watch Dog Timer (WDT) |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, 152-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK, WPA2-Enterprise |
| Authentication Method | RADIUS |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Device | External power adapter |
| Power Consumption Operational | 13 watt |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows Vista / XP / 7 / 8, Windows 10 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Antenna | |
| Antenna | Internal |
| Directivity | Omni-directional |
