NAS server - 7 bays - SATA 3Gb/s - HDD - RAID 0, 1, 5, 6, 10, 50, JBOD - RAM 8 GB - 10 Gigabit Ethernet - iSCSI support
| Main Specifications | |
|---|---|
| Product Description | Thecus Technology N7770-10G - NAS server |
| Device Type | NAS server |
| Host Connectivity | 10 Gigabit Ethernet |
| Installed Devices / Modules Qty | 7 (max) |
| Dimensions (WxDxH) | 8.3 in x 10.6 in x 12.6 in |
| Weight | 18.52 lbs () |
| Processor | 1 x Intel Core i3 2120 3.3 GHz |
| Storage Controller | RAID SATA 3Gb/s RAID 0, 1, 5, 6, 10, 50, JBOD |
| Networking | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| IP Cameras Supported | 10 |
| RAM | 8 GB |
| System Requirements | UNIX, Linux, Apple MacOS X, Microsoft Windows XP or later, Microsoft Windows Server 2003 or later |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | NAS server |
| Host Connectivity | 10 Gigabit Ethernet |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 7 (max) |
| Width | 8.3 in |
| Depth | 10.6 in |
| Height | 12.6 in |
| Weight | 18.52 lbs () |
| Built-in Devices | Status LCD, LED panel |
| Expansion / Connectivity | |
| Expansion Bays | 7 (total) / 7 (free) x hot-swap |
| Interfaces | 2 x Ethernet 1000Base-T - RJ-45 ¦ 1 x HDMI output ¦ 6 x USB 2.0 - Type A ¦ 2 x USB 3.0 - Type A ¦ 1 x VGA - HD-15 ¦ 1 x Ethernet 10Gb |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | VCCI, C-Tick, BSMI, FCC, RoHS, WEEE, AES-256 |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| Network / Transport Protocol | TCP/IP, AppleTalk, iSCSI, FTP, SMB, DDNS |
| Remote Management Protocol | HTTP, HTTPS, TFTP, SSH |
| Network Services Compatibility | DDNS, Microsoft CIFS, Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS |
| Features | Load balancing, WOL, auto-uplink (auto MDI/MDI-X), print server, IPv6 support, TLB, iTunes server, port forwarding, IPv4 support, ALB |
| Compliant Standards | IEEE 802.3ad (LACP), UPnP |
| Power | |
| Power Device | Internal power supply |
| Power Provided | 300 Watt |
| Software / System Requirements | |
| Software Included | Acronis True Image, Thecus Backup Utility |
| OS Required | UNIX, Linux, Apple MacOS X, Microsoft Windows XP or later, Microsoft Windows Server 2003 or later |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 3Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD |
| Hard Drive | |
| Type | HDD - hot-swap |
| Processor / Memory | |
| Processors Installed | 1 x Intel Core i3 2120 3.3 GHz |
| RAM | 8 GB (installed) / 32 GB (supported) - DDR3 |
| Security DVR | |
| IP Cameras Supported | 10 |
