Ultrabook - Intel Core i5 - 6300U / up to 3 GHz - Win 10 Pro 64-bit - HD Graphics 520 - 8 GB RAM - 192 GB SSD - 12.5" IPS touchscreen 1920 x 1080 (Full HD) - Wi-Fi 5, 802.11ad (WiGig) - midnight black - kbd: US
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkPad Yoga 260 - 12.5" - Intel Core i5 - 6300U - 8 GB RAM - 192 GB SSD - US |
| Product Type | Ultrabook - flip design |
| Operating System | Win 10 Pro 64-bit |
| Processor | Intel Core i5 (6th Gen) - 6300U / 2.4 GHz, up to 3 GHz / 3 MB Cache |
| Memory | 8 GB DDR4 (1 x 8 GB) |
| Storage | 192 GB SSD |
| Display | 12.5" LED backlight touchscreen 1920 x 1080 / Full HD |
| Graphics | Intel HD Graphics 520 |
| Input Device | Digitizer, TrackPoint, digital pen, UltraNav |
| Keyboard | US |
| Keyboard Backlight | Yes |
| Integrated Webcam | Yes |
| Networking | Bluetooth, 802.11a/b/g/n/ac, 802.11ad (WiGig) |
| Battery | 4-cell - up to 10 hours |
| Features | Ambient light sensor |
| Dockable | Yes |
| Security | Trusted Platform Module (TPM 1.2 and TPM 2.0), fingerprint reader |
| Color | Midnight black |
| Dimensions (WxDxH) | 12.2 in x 8.7 in x 0.7 in |
| Weight | 2.91 lbs |
| Localization | Language: English |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - 1 year - pick-up and return |
| General | |
| Product Type | Ultrabook - flip design |
| Operating System | Windows 10 Pro 64-bit Edition |
| Memory | |
| RAM | 8 GB (1 x 8 GB) |
| Max RAM Supported | 16 GB |
| Technology | DDR4 SDRAM |
| Speed | 2133 MT/s / PC4-17000 |
| Form Factor | SO-DIMM 260-pin |
| Slots Qty | 1 |
| Empty Slots | 0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year - pick-up and return |
| Miscellaneous | |
| Color | Midnight black |
| Case Material | Carbon fiber |
| Integrated Options | Ambient light sensor |
| Dockable | Yes |
| Security | Trusted Platform Module (TPM 1.2 and TPM 2.0), fingerprint reader |
| Features | Administrator password, hard drive password, power-on password, Intel Active Management Technology (iAMT), 1 USB 3.0 (Always On), 3D gyrometer, 3D accelerometer, 3D magnetometer, 3D compass, MIL-STD-810G tested |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Included Accessories | Power adapter |
| Compliant Standards | RoHS |
| Localization | Language: English |
| Storage | |
| Main Storage | 192 GB SSD M.2 SATA 6Gb/s |
| Battery | |
| Technology | 4-cell lithium polymer |
| Capacity | 44 Wh |
| Run Time | Up to 10 hours |
| Display | |
| Type | 12.5" - IPS |
| LCD Backlight Technology | LED backlight |
| Touchscreen | Yes (10-point multi-touch) |
| Resolution | 1920 x 1080 (Full HD) |
| Widescreen | Yes |
| Image Aspect Ratio | 16:9 |
| Image Brightness | 300 cd/m² |
| Features | Anti-glare |
| Communications | |
| Wireless | Bluetooth, 802.11a/b/g/n/ac, 802.11ad (WiGig) |
| Wireless Controller | Intel Tri-Band Wireless-AC 18260 - M.2 Card |
| Features | Gigabit Ethernet via optional Ethernet (RJ-45) adapter |
| Dimensions & Weight | |
| Dimensions (WxDxH) | 12.2 in x 8.7 in x 0.7 in |
| Weight | 2.91 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (6th Gen) 6300U / 2.4 GHz |
| Max Turbo Speed | 3 GHz |
| Number of Cores | Dual-Core |
| Cache | 3 MB |
| 64-bit Computing | Yes |
| Features | Hyper-Threading Technology, integrated memory controller, Intel Turbo Boost Technology 2.0, Intel Smart Cache |
| Audio & Video | |
| Graphics Processor | Intel HD Graphics 520 |
| Camera | Yes - 720p |
| Sound | Stereo speakers, two microphones |
| Codec | CX11852 |
| Compliant Standards | High Definition Audio, Dolby Home Theater v4 |
| Input | |
| Type | Keyboard, digitizer, TrackPoint, digital pen, UltraNav |
| Keyboard Backlight | Yes |
| Keyboard Layout | US |
| Features | Spill-resistant, multi-touch touchpad |
| AC Adapter | |
| Input | (50/60 Hz) |
| Output | 45 watt, 20 V |
| Connections & Expansion | |
| Interfaces Details | 2 x USB 3.0 ¦ Mini DisplayPort ¦ HDMI ¦ OneLink+ connector ¦ Headphone/microphone combo jack |
| Memory Card Reader | Yes (microSDXC UHS) |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
