Server - blade 1-way - no CPU - RAM 0 GB - SATA/SAS - hot-swap 2.5", 3.5" bay(s) - no HDD - Radeon - monitor: none
| Main Specifications | |
|---|---|
| Product Description | HPE ProLiant SL4545 G7 - blade no CPU - 0 GB - no HDD |
| Type | Server - blade |
| Server Scalability | 1-way |
| Processor | No CPU |
| RAM | 0 GB (installed) / 192 GB (max) - DDR3 SDRAM |
| Storage Controller | RAID SATA (Smart Array B110i) |
| Server Storage Bays | Hot-swap 2.5", 3.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | ATI Radeon |
| General | |
| Type | Server |
| Product Form Factor | Blade |
| Server Scalability | 1-way |
| Hot-Swap Bays Qty | 62 |
| Expansion / Connectivity | |
| Bays | 2 (total) / 2 (free) x hot-swap 2.5" SFF ¦ 60 (total) / 60 (free) x hot-swap 3.5" LFF |
| Slots | 12 (total) / 12 (free) x DIMM 240-pin ¦ 1 (total) / 1 (free) x CPU |
| Interfaces | 3 x USB (2 front, 1 internal) ¦ 1 x VGA (1 in front) ¦ 1 x serial (1 rear) ¦ 1 x HPE iLO ¦ 2 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Compliant Standards | ACPI 2.0b |
| RAM | |
| Installed Size | 0 GB (installed) / 192 GB (max) |
| Technology | DDR3 SDRAM |
| Form Factor | DIMM 240-pin |
| Slots | 12 (total) / 12 (empty) |
| Storage Controller | |
| Type | RAID - SATA |
| Storage Controller Name | Smart Array B110i |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | ATI Radeon |
| Operating System / Software | |
| OS Certified | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Ubuntu |
| Hard Drive | |
| Type | No HDD |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
