Server - rack-mountable 1U - 1-way - no CPU - RAM 0 GB - SATA - hot-swap 3.5" bay(s) - no HDD - AST2400 - Gigabit Ethernet - monitor: none - black
| Main Specifications | |
|---|---|
| Product Description | Supermicro SuperServer 5019S-MN4 - rack-mountable no CPU - 0 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 1U |
| Server Scalability | 1-way |
| Processor | No CPU |
| Processor Socket | LGA1151 Socket |
| RAM | 0 GB (installed) / 64 GB (max) - DDR4 SDRAM - ECC |
| Storage Controller | SATA (SATA 6Gb/s) |
| Server Storage Bays | Hot-swap 3.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | ASPEED AST2400 |
| Networking | 1GbE |
| Power | AC 120/230 V (50/60 Hz) |
| Color | Black |
| Dimensions (WxDxH) | 17.2 in x 19.8 in x 1.7 in |
| Weight | 17.64 lbs |
| Manufacturer Warranty | Limited warranty - labor - 3 years ¦ Limited warranty - parts - 1 year |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 1-way |
| Hot-Swap Bays Qty | 4 |
| Color | Black |
| Expansion / Connectivity | |
| Bays | 4 (total) / 4 (free) x hot-swap 3.5" |
| Slots | 1 (total) / 1 (free) x CPU ¦ 4 (total) / 4 (free) x DIMM 288-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x8 mode) ¦ 1 (total) / 1 (free) x M.2 Card |
| Interfaces | 4 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x management (NIC) - RJ-45 ¦ 2 x USB 2.0 ¦ 1 x VGA ¦ 1 x serial ¦ 2 x USB 3.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - labor - 3 years ¦ Limited warranty - parts - 1 year |
| Miscellaneous | |
| Included Accessories | CPU Heatsink, air shroud, riser card |
| Cables Included | Serial ATA cable (4 pcs.) ¦ SGPIO cable |
| Theft/Intrusion Protection | Chassis intrusion switch |
| Compliant Standards | RoHS |
| RAM | |
| Installed Size | 0 GB (installed) / 64 GB (max) |
| Technology | DDR4 SDRAM - ECC |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 4 (empty) |
| Features | Unbuffered |
| Networking | |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | 4 x Intel I210-AT |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Features | ACPI support, KVM over IP support |
| Power | |
| Device Type | Power supply |
| Installed Qty | 1 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 350 watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Power Factor Correction | Yes |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 4 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | ASPEED AST2400 |
| Video Interfaces | VGA |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 19.8 in |
| Height | 1.7 in |
| Weight | 17.64 lbs |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA1151 Socket |
| Chipset Type | Intel C236 |
