Server - rack-mountable 2U - 2-way - no CPU - RAM 0 GB - SATA - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet, 10 Gigabit Ethernet - monitor: none
| Main Specifications | |
|---|---|
| Product Description | Intel Server System R2208WTTYC1R - rack-mountable no CPU - 0 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 2U |
| Server Scalability | 2-way |
| Processor | No CPU |
| Processor Socket | LGA2011-v3 Socket |
| RAM | 0 GB (installed) / 3072 GB (max) - DDR4 SDRAM - ECC |
| Storage Controller | RAID (SATA 6Gb/s / SAS 12Gb/s) |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Networking | 1GbE, 10GbE |
| Power | AC 120/230 V (50/60 Hz) |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 16.9 in x 28 in x 3.4 in |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 2U |
| Server Scalability | 2-way |
| Front Accessible Bays Qty | 1 |
| Hot-Swap Bays Qty | 8 |
| Expansion / Connectivity | |
| Bays | 8 (total) / 8 (free) x hot-swap 2.5" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line |
| Slots | 2 (total) / 2 (free) x CPU ¦ 24 (total) / 24 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 ¦ 3 (total) / 3 (free) x PCIe 3.0 x8 ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 ¦ 1 (total) / 1 (free) x PCIe 2.0 x4 |
| Interfaces | 2 x VGA (1 front, 1 rear) ¦ 5 x USB 3.0 (2 front, 3 rear) ¦ 2 x LAN (10Gigabit Ethernet) - RJ-45 ¦ 1 x serial - RJ-45 ¦ 1 x management - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | 2 x CPU Heatsink, air duct, 3 x riser cards |
| Cables Included | Mini SAS HD cable (2 pcs.) |
| RAM | |
| Installed Size | 0 GB (installed) / 3072 GB (max) |
| Technology | DDR4 SDRAM - ECC |
| Form Factor | DIMM 288-pin |
| Slots | 24 (total) / 24 (empty) |
| Networking | |
| Type | Integrated |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Ethernet Controller | Intel X540 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Remote Management Controller | Emulex Pilot 3 iBMC |
| Power | |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 1100 watt |
| Storage Controller | |
| Type | 1 x RAID - integrated |
| Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| Channel Qty | 10 |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Type | Integrated |
| Video Interfaces | VGA |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 16.9 in |
| Depth | 28 in |
| Height | 3.4 in |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA2011-v3 Socket |
| Chipset Type | Intel C612 |
