Server - blade 2-way - no CPU - RAM 0 GB - no HDD - Gigabit Ethernet, 10 Gigabit Ethernet - monitor: none
| Main Specifications | |
|---|---|
| Product Description | Intel Compute Module HNS2600TP24SR - blade no CPU - 0 GB - no HDD |
| Type | Server - blade |
| Server Scalability | 2-way |
| Processor | No CPU |
| Processor Socket | LGA2011-v3 Socket |
| RAM | 0 GB (installed) / 1 TB (max) - DDR4 SDRAM |
| Storage Controller | SATA (SATA 6Gb/s / SAS 12Gb/s) |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Networking | 1GbE, 10GbE |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | Server |
| Product Form Factor | Blade |
| Server Scalability | 2-way |
| Expansion / Connectivity | |
| Slots | 2 (total) / 2 (free) x CPU ¦ 16 (total) / 16 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 (riser card only) ¦ 2 (total) / 2 (free) x PCIe 3.0 x24 (riser card only) |
| Interfaces | 1 x VGA ¦ 2 x LAN (10Gigabit Ethernet) (SFP+) - SFP+ ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 4 x USB 2.0 ¦ 1 x serial |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | 2 x CPU Heatsink, PCI-Express (1x16) Riser Card, air duct, bridge board, node power board, 1U node tray |
| RAM | |
| Installed Size | 0 GB (installed) / 1 TB (max) |
| Technology | DDR4 SDRAM |
| Form Factor | DIMM 288-pin |
| Slots | 16 (total) / 16 (empty) |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet, 2 x SFP+ |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Storage Controller | |
| Type | 1 x SATA - integrated |
| Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| Channel Qty | 6 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Type | Integrated |
| Video Interfaces | VGA |
| Hard Drive | |
| Type | No HDD |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA2011-v3 Socket |
| Chipset Type | Intel C612 |
