Wireless bridge - Wi-Fi 5 - 5 GHz
| Main Specifications | |
|---|---|
| Product Description | EnGenius EnStation AC - wireless bridge - Wi-Fi 5 |
| Device Type | Wireless bridge |
| Form Factor | External - outdoor |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 5 GHz |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 7.5 in x 1.5 in |
| General | |
| Device Type | Wireless bridge |
| Ruggedized Design | Outdoor |
| Built-in Devices | Wireless access point |
| Depth | 7.5 in |
| Height | 1.5 in |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x 1000Base-T - RJ-45 |
| Miscellaneous | |
| Compliant Standards | IP55 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 866 Mbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Remote Management Protocol | SNMP 1, SNMP 2, SNMP 3, CLI |
| Frequency Band | 5 GHz |
| Status Indicators | Power, status |
| Features | Power over Ethernet (PoE), manageable, MAC address filtering, VPN passthrough, Wireless Distribution System (WDS) support, Access Point operational mode, firmware upgradable, Spanning Tree Protocol (STP) support, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), DHCP server, hidden SSID, wireless bridge mode, Wireless Client Mode, DHCP client, Management Information Base (MIB) |
| Encryption Algorithm | AES, 128-bit WEP, 64-bit WEP, 152-bit WEP, TKIP, WPA, WPA2, WPA-PSK, WPA-Enterprise, WPA2-Enterprise |
| Compliant Standards | IEEE 802.11a, IEEE 802.3af, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 0 - 90% |
| Antenna | |
| Antenna Qty | 1 |
| Directivity | Directional |
| Gain Level | 19 dBi |
