Wireless router 4-port switch - 1GbE Dual Band
| Main Specifications | |
|---|---|
| Product Description | TP-Link Touch P5 AC1900 - wireless router - Wi-Fi 5 - desktop |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| WAN Ports Qty | 1 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 1.9 Gbps |
| Performance | Maximum throughput (2.4 GHz): 600 Mbps ¦ Maximum throughput (5 GHz): 1.3 Gbps |
| Network / Transport Protocol | PPTP, L2TP, IPSec, PPPoE |
| Features | DMZ port, NAT support, auto-negotiation, auto-uplink (auto MDI/MDI-X), SPI, DoS attack prevention, print server, MAC address filtering, IPv6 support, VPN passthrough, parental control, IP address filtering, firmware upgradable, WMM support, QoS, virtual server support, DHCP server, Samba support, FTP server, reset button, bandwidth control, IPv4 support, port triggering |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac |
| Dimensions (WxDxH) | 11.2 in x 6.2 in x 2 in |
| General | |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 1.9 Gbps |
| Performance | Maximum throughput (2.4 GHz): 600 Mbps ¦ Maximum throughput (5 GHz): 1.3 Gbps |
| Network / Transport Protocol | PPTP, L2TP, IPSec, PPPoE |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK |
| Wi-Fi Rating | AC1900 |
| Features | DMZ port, NAT support, auto-negotiation, auto-uplink (auto MDI/MDI-X), SPI, DoS attack prevention, print server, MAC address filtering, IPv6 support, VPN passthrough, parental control, IP address filtering, firmware upgradable, WMM support, QoS, virtual server support, DHCP server, Samba support, FTP server, reset button, bandwidth control, IPv4 support, port triggering |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, FCC, RoHS |
| Processor | 1 GHz |
| Built-in Devices | 4.3" touch screen display |
| Expansion / Connectivity | |
| Interfaces | LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 3.0: 1 x 9 pin USB Type A ¦ USB 2.0: 1 x 4 pin USB Type A |
| Miscellaneous | |
| Cables Included | 1 x network cable |
| Power | |
| Power Device | External power adapter |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 11.2 in |
| Depth | 6.2 in |
| Height | 2 in |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 3 |
