Wireless access point - Wi-Fi - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | D-Link DWL-6700AP - wireless access point - Wi-Fi |
| Device Type | Wireless access point |
| Form Factor | External |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz, 5 GHz |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 11 in x 4.5 in x 2 in |
| Weight | 17.46 oz |
| General | |
| Device Type | Wireless access point |
| Width | 11 in |
| Depth | 4.5 in |
| Height | 2 in |
| Weight | 17.46 oz |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Compliant Standards | C-Tick, cUL, IC, FCC, AES, TELEC, LVD, IP55, NCC, EN 300 328, EN 301 893 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 300 Mbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n |
| Remote Management Protocol | HTTP, HTTPS, SSH |
| Frequency Band | 2.4 GHz, 5 GHz |
| Features | MAC address filtering, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), plastic housing, Virtual Access Points (VAP) |
| Encryption Algorithm | AES, TKIP, WPA, WPA2 |
| Compliant Standards | IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
| Directivity | Omni-directional |
