Wi-Fi range extender - Wi-Fi 5 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | Edimax EW-7438AC - Wi-Fi range extender - Wi-Fi 5 |
| Device Type | Wi-Fi range extender |
| Form Factor | External |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz, 5 GHz |
| Power | AC 120/230 V (50 - 60 Hz) |
| Dimensions (WxDxH) | 2.3 in x 1.6 in x 3.6 in |
| Weight | 3.74 oz |
| General | |
| Device Type | Wi-Fi range extender |
| Width | 2.3 in |
| Depth | 1.6 in |
| Height | 3.6 in |
| Weight | 3.74 oz |
| Expansion / Connectivity | |
| Interfaces | 1 x 100Base-TX - RJ-45 |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz, 5 GHz |
| Status Indicators | Power, signal strength, LAN, wireless, WPS |
| Features | Access Point operational mode, firmware upgradable, Wi-Fi Protected Setup (WPS), wireless bridge mode |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Wi-Fi Protected Setup, IEEE 802.11ac |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 3 |
