Standalone DVR - 16 channels 12 TB - networked - 1.5U - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | exacqVision ELP-Series 1604-12T-ELPR - standalone DVR - 16 channels |
| Device Type | Standalone DVR - 16 channels - networked - rack-mountable - 1.5U |
| IP Cameras Supported | 24 |
| Frame Rate | 200 fps |
| Compression Format | MJPEG, MPEG-4 |
| Hard Drive | 12 TB |
| Hard Drive(s) Supported | Quantity: 2 |
| Voltage | 120 / 230 V |
| Dimensions (WxDxH) | 17 in x 18.9 in x 2.6 in |
| Weight | 24.91 lbs |
| Manufacturer Warranty | 3 years |
| General | |
| Device Type | Standalone DVR - rack-mountable - 1.5U |
| Video Channels | 16 |
| IP Cameras Supported | 24 |
| Audio Channels | 4 |
| Compression Format | MJPEG, MPEG-4 |
| Package Content | DVR |
| OS Provided | Ubuntu 14.04 |
| Software Included (Y) | exacqVision Professional client, exacqVision Professional server |
| Compliant Standards | FCC, cULus |
| Warranty | 3 years |
| Power | |
| Voltage | 120 / 230 V |
| Power Consumption | 130 watt |
| Environmental Parameters | |
| Min Operating Temperature | 40.1 °F |
| Max Operating Temperature | 95 °F |
| Hard Drive | |
| Quantity Supported | 2 |
| Capacity | 12 TB |
| Connections | |
| Video Input Ports | BNC x 16 |
| Video Output Ports | DVI-D x 1, HDMI x 1, DisplayPort x 1, BNC x 1 |
| Audio Input Ports | Terminal block x 4, mini-phone 3.5 mm x 2 |
| Audio Output Ports | Mini-phone 3.5 mm x 1 |
| Alarm Ports | Alarm input x 4, alarm output x 2 |
| Camera Control Interface (PTZ) | RS-485 |
| Network Port | 10/100/1000Base-T x 2 |
| Other Ports | PS/2 x 2, USB 2.0 x 2, USB 3.0 x 2 |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 18.9 in |
| Height | 2.6 in |
| Weight | 24.91 lbs |
| Security DVR | |
| Frame Rate (Record) | 200 fps |
| Networked | Yes |
| Features | Pan/Tilt/Zoom support |
| Video Server | |
| CPU | Intel Celeron |
| RAM | 2 GB |
