Wireless router 1GbE 2.4 GHz
| Main Specifications | |
|---|---|
| Product Description | Zyxel UAG50 - wireless router - Wi-Fi - desktop |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| WAN Ports Qty | 1 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz |
| Data Transfer Rate | 300 Mbps |
| Capacity | Concurrent users: 50 ¦ Maximum number of concurrent sessions: 16384 ¦ Dynamic accounts: 256 ¦ Maximum number of configured SSIDs: 8 ¦ DHCP pool: 253 ¦ Billing profiles: 10 |
| Network / Transport Protocol | PPTP, PPPoE, SMTP, DHCP, DDNS |
| Routing Protocol | Static IP routing |
| Remote Management Protocol | SNMP 2c, HTTP, HTTPS |
| Features | Firewall protection, Syslog support, dynamic DNS server, VPN passthrough, Multiple SSID support, HTTP proxy, bandwidth control, 2T2R MIMO technology, DHCP client, Captive Portal, built-in billing system |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n |
| Power | AC 100/240 V (50/60 Hz) |
| Dimensions (WxDxH) | 4.3 in x 6.1 in x 3.5 in |
| Weight | 29.22 oz |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz |
| Data Transfer Rate | 300 Mbps |
| Capacity | Concurrent users: 50 ¦ Maximum number of concurrent sessions: 16384 ¦ Dynamic accounts: 256 ¦ Maximum number of configured SSIDs: 8 ¦ DHCP pool: 253 ¦ Billing profiles: 10 |
| Network / Transport Protocol | PPTP, PPPoE, SMTP, DHCP, DDNS |
| Routing Protocol | Static IP routing |
| Remote Management Protocol | SNMP 2c, HTTP, HTTPS |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, WPA, WPA2 |
| Authentication Method | RADIUS |
| Features | Firewall protection, Syslog support, dynamic DNS server, VPN passthrough, Multiple SSID support, HTTP proxy, bandwidth control, 2T2R MIMO technology, DHCP client, Captive Portal, built-in billing system |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, FCC Part 15 B, EMC |
| Built-in Devices | Printer |
| Expansion / Connectivity | |
| Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 1 x 5 pin Micro-USB Type B ¦ Antenna: 2 x R-SMA |
| Miscellaneous | |
| Included Accessories | Thermal paper, paper roller |
| Cables Included | 1 x micro-USB to LAN adapter |
| MTBF | 42,486 hours |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100/240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Dimensions & Weight | |
| Width | 4.3 in |
| Depth | 6.1 in |
| Height | 3.5 in |
| Weight | 29.22 oz |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 2 |
