Tower - ATX - no power supply (ATX / PS/2) - metallic dark gray, black interior - USB/Audio
| Main Specifications | |
|---|---|
| Product Description | Cooler Master MasterCase 5 - tower - ATX |
| Product Type | System cabinet |
| Form Factor | Tower |
| Color | Metallic dark gray, black interior |
| I/O Connectors | 1 x microphone ¦ 1 x audio line-out ¦ 2 x USB 3.0 |
| Supported Motherboards | ATX, microATX, Mini-ITX |
| System Cabinet Features | Top panel dust filter, front dust filter, cable management system, bottom dust filter, water cooling ready, supports 120/140 mm radiator in rear, supports 240/280 mm radiator in front panel |
| Power Device | No power supply (ATX / PS/2) |
| Dimensions (WxDxH) | 9.3 in x 20.2 in x 21.6 in |
| Weight | 23.37 lbs |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Form Factor | Tower |
| Max Mainboard Size | ATX |
| Supported Motherboards | ATX, microATX, Mini-ITX |
| Internal Bays Qty | 4 |
| Front Accessible Bays Qty | 2 |
| Color | Metallic dark gray, black interior |
| Cooling System | Front: 140 mm fan x 1 / 1200 rpm / 55 cfm / 24 dBA ¦ Rear: 140 mm fan x 1 / 1200 rpm / 55 cfm / 24 dBA ¦ Front: 120/140 mm fan mount x 2 ¦ Top: 120/140 mm fan mount x 2 ¦ Rear: 120/140 mm fan mount x 1 |
| CPU Cooler Max Height | 190 mm |
| Video Card Max Length | 412 mm |
| System Cabinet Features | Top panel dust filter, front dust filter, cable management system, bottom dust filter, water cooling ready, supports 120/140 mm radiator in rear, supports 240/280 mm radiator in front panel |
| Expansion / Connectivity | |
| Expansion Bays | 3 (total) / 3 (free) x front accessible - 5.25" ¦ 2 (total) / 2 (free) x internal - 2.5" / 3.5" shared ¦ 2 (total) / 2 (free) x internal - 2.5" |
| Expansion Slots | 7 |
| Interfaces | 1 x microphone - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 2 x USB 3.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Power | |
| Power Device | No power supply |
| Specification Compliance | ATX / PS/2 |
| Dimensions & Weight | |
| Width | 9.3 in |
| Depth | 20.2 in |
| Height | 21.6 in |
| Weight | 23.37 lbs |
