SFP (mini-GBIC) transceiver module - LC multi-mode - up to 1640 ft - 850 nm
| Main Specifications | |
|---|---|
| Product Description | Vivotek SFP-1000-MM85-X5I - SFP (mini-GBIC) transceiver module |
| Device Type | SFP (mini-GBIC) transceiver module - LC multi-mode |
| Form Factor | Plug-in module |
| Data Transfer Rate | 1.25 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 1640 ft |
| Dimensions (WxDxH) | 0.6 in x 2.2 in x 0.5 in |
| General | |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 1 x network - LC multi-mode x 2 |
| Miscellaneous | |
| Compliant Standards | MSA, EN 60825-1, FDA 21CFR1040.10, FDA 21CFR1040.11 |
| Networking | |
| Connectivity Technology | Wired |
| Data Transfer Rate | 1.25 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 1640 ft |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 185 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 0.6 in |
| Depth | 2.2 in |
| Height | 0.5 in |
