USB 3.0 to SATA III 6Gbps with RAID - Hard drive array - 2 bays (SATA-600) - USB 3.0 (external) - for P/N: DKWG30DPHPD, DKWG30DPHPDU, HB30A3A1CSFS, SVA5H2NEUA, USB3DDOCKFT
| Main Specifications | |
|---|---|
| Product Description | StarTech Dual Bay 2.5in Hard Drive Enclosure - USB 3.0 to SATA III 6Gbps with RAID - hard drive array |
| Device Type | Hard drive array |
| Color | Black |
| Max Supported Capacity | 4 TB |
| Interface | USB 3.0 |
| Installed Devices / Modules Qty | 0 (installed) / 2 (max) |
| Supported Drives | SATA-600 |
| Storage Controller | RAID (SATA 6Gb/s) - RAID 0, 1, JBOD, BIG |
| Power | AC 100/230 V |
| Dimensions (WxDxH) | 2 in x 5.2 in x 3.5 in |
| Weight | 12.34 oz |
| Designed For | P/N: DKWG30DPHPD, DKWG30DPHPDU, HB30A3A1CSFS, SVA5H2NEUA, USB3DDOCKFT |
| General | |
| Device Type | Hard drive array |
| Enclosure Color | Black |
| Expansion / Connectivity | |
| Expansion Bays | 2 (total) / 2 (free) x internal - 2.5" |
| Interfaces | 1 x USB 3.0 - 9 pin USB Type A ¦ 2 x SATA 6Gb/s - 22 pin Serial ATA |
| Miscellaneous | |
| Features | Built-in cooling fan |
| Cables Included | 1 x USB 3.0 cable ¦ 1 x USB power cable |
| Compliant Standards | FCC, RoHS |
| Storage | |
| Max Supported Capacity | 4 TB |
| HDD Array External Interface | USB 3.0 |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100/230 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Storage Controller | |
| Type | RAID (USB 3.0) |
| Channel Qty | 2 |
| Interface Type | SATA 6Gb/s |
| Max Storage Devices Qty | 2 |
| RAID Level | RAID 0, RAID 1, JBOD, BIG |
| Dimensions & Weight | |
| Width | 2 in |
| Depth | 5.2 in |
| Height | 3.5 in |
| Weight | 12.34 oz |
| Compatibility Information | |
| Designed For | P/N: DKWG30DPHPD, DKWG30DPHPDU, HB30A3A1CSFS, SVA5H2NEUA, USB3DDOCKFT |
| Chassis | |
| Installed Devices / Modules Qty | 0 |
| Supported Devices / Modules Qty | 2 |
| Supported Drives | SATA-600 |
