Wireless router 4-port switch Dual Band
| Main Specifications | |
|---|---|
| Product Description | Edimax EW-7208APC - wireless router - Wi-Fi 5 - desktop |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| WAN Ports Qty | 1 |
| Data Link Protocol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Features | Firewall protection, VLAN support, SPI, DoS attack prevention, Access Point operational mode, firmware upgradable, WISP mode, QoS, WPS, Multiple SSID support, wireless bridge mode, reset button, iQoS, wireless extender mode |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Dimensions (WxDxH) | 7.5 in x 5.6 in x 1.7 in |
| Weight | 9.17 oz |
| General | |
| Device Type | Wireless router - 4-port switch (integrated) |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, WPA, WPA2 |
| Features | Firewall protection, VLAN support, SPI, DoS attack prevention, Access Point operational mode, firmware upgradable, WISP mode, QoS, WPS, Multiple SSID support, wireless bridge mode, reset button, iQoS, wireless extender mode |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, FCC |
| RAM | 64 MB |
| Flash Memory | 4 MB |
| Status Indicators | Power, wireless, Internet |
| Expansion / Connectivity | |
| Interfaces | WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 4 x 10Base-T/100Base-TX - RJ-45 |
| Miscellaneous | |
| Cables Included | 1 x network cable |
| Power | |
| Power Device | External power adapter |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 7.5 in |
| Depth | 5.6 in |
| Height | 1.7 in |
| Weight | 9.17 oz |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 3 |
