Mixer amplifier - powered - 60 Watt
| Main Specifications | |
|---|---|
| Product Description | TOA BG-2000 SERIES BG-2060 CU mixer amplifier |
| Type | Mixer amplifier - powered |
| Frequency Response | 50 Hz - 20 kHz |
| Mic Phantom Power | 24 V |
| Output Power / Total | 60 Watt |
| Mic Channels | 1 mono |
| Line Channels | 3 mono / 2 stereo |
| Color | Black |
| Dimensions (WxDxH) | 10.4 in - 10.5 in - 3.7 in |
| Weight | 11.68 lbs |
| General | |
| Type | Mixer amplifier |
| Miscellaneous | |
| Color | Black |
| Power | |
| Frequency | 60 Hz |
| Connections | |
| Connector Type | 1 x microphone (terminal block (clamp)) - rear ¦ 1 x balanced audio input (3 pin terminal block) - rear ¦ 2 x audio line-in (2 pin terminal block) - rear ¦ 2 x audio line-in (RCA x 2) - rear ¦ 1 x remote control (2 pin terminal block) - rear ¦ 1 x audio line-out (2 pin terminal block) - rear ¦ 1 x music on hold (3 pin terminal block) - rear ¦ 1 x speaker output (4 pin terminal block) - rear |
| Dimensions & Weight | |
| Width | 10.4 in |
| Depth | 10.5 in |
| Height | 3.7 in |
| Weight | 11.68 lbs |
| Mixer | |
| Frequency Response | 50 Hz - 20 kHz |
| Powered | Powered |
| Mic Phantom Power | 24 V |
| Control Types | Knobs |
| Features | Bass & treble control, 25V/70V or 4 Ohm operation |
| Channel Description | |
| Mic Channels | 1 mono |
| Line Channels | 3 mono / 2 stereo |
| Mixer Amplifier | |
| Output Power / Total | 60 Watt |
