Switch - managed - 8 x 10GBase-T + 2 x 10 Gigabit SFP+ + 2 x combo 10 Gigabit SFP+ - desktop, rack-mountable
| Main Specifications | |
|---|---|
| Product Description | D-Link Web Smart DXS-1210-12TC - switch - 12 ports - managed - rack-mountable |
| Device Type | Switch - 12 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 8 x 10GBase-T + 2 x 10 Gigabit SFP+ + 2 x combo 10 Gigabit SFP+ |
| Performance | Switching capacity: 240 Gbps ¦ Forwarding performance: 178.56 Mpps |
| Capacity | ACL entries: 512 ¦ ACL rules: 512 ¦ ARP entries: 128 ¦ IPv4 routes (static): 32 ¦ IPv6 routes (static): 32 ¦ IGMP groups: 1000 ¦ QoS hardware queues per port: 8 |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | Static IPv4 routing, static IPv6 routing |
| Remote Management Protocol | SNMP 1, SNMP 3, SNMP 2c, CLI, Telnet, HTTP, RMON 1, RMON 2 |
| Features | BOOTP support, DHCP client, TFTP support, SNMP trap, auto-uplink (auto MDI/MDI-X), SNTP support, DHCP relay, system log, Cable Diagnostics Function, ACL support, DHCP snooping, IP source guard, Safeguard Engine, DoS attack prevention, DAI, Port Security, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, CoS, DSCP support, QoS, DWRR, SPQ, DRR, ToS, MLD snooping, MSTP support, RSTP support, STP support, store and forward, ERPS, flow control, VLAN support, IGMP snooping, D-Link Green Technology, bandwidth control, port based access control, host based access control, GVRP, LLDP support, port mirroring, IP-MAC binding, DHCP server |
| Compliant Standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3z, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.3 in x 8.3 in x 1.7 in |
| Weight | 6.94 lbs |
| General | |
| Device Type | Switch - 12 ports - managed |
| Enclosure Type | Desktop, rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 8 x 10GBase-T + 2 x 10 Gigabit SFP+ + 2 x combo 10 Gigabit SFP+ |
| Performance | Switching capacity: 240 Gbps ¦ Forwarding performance: 178.56 Mpps |
| Capacity | ACL entries: 512 ¦ ACL rules: 512 ¦ ARP entries: 128 ¦ IPv4 routes (static): 32 ¦ IPv6 routes (static): 32 ¦ IGMP groups: 1000 ¦ QoS hardware queues per port: 8 |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | Static IPv4 routing, static IPv6 routing |
| Remote Management Protocol | SNMP 1, SNMP 3, SNMP 2c, CLI, Telnet, HTTP, RMON 1, RMON 2 |
| Encryption Algorithm | PEAP, TLS, TTLS, SSL, SSL 2.0, SSL 3.0 |
| Authentication Method | RADIUS, TACACS+, Extensible Authentication Protocol (EAP), internal user database, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
| Features | BOOTP support, DHCP client, TFTP support, SNMP trap, auto-uplink (auto MDI/MDI-X), SNTP support, DHCP relay, system log, Cable Diagnostics Function, ACL support, DHCP snooping, IP source guard, Safeguard Engine, DoS attack prevention, DAI, Port Security, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, CoS, DSCP support, QoS, DWRR, SPQ, DRR, ToS, MLD snooping, MSTP support, RSTP support, STP support, store and forward, ERPS, flow control, VLAN support, IGMP snooping, D-Link Green Technology, bandwidth control, port based access control, host based access control, GVRP, LLDP support, port mirroring, IP-MAC binding, DHCP server |
| Compliant Standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3z, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x |
| Expansion / Connectivity | |
| Interfaces | 10 x 10GBase-T RJ-45 ¦ 4 x 10Gbit LAN SFP+ |
| Miscellaneous | |
| Compliant Standards | FCC, C-Tick, VCCI, BSMI, CCC, cUL, CB |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 42.65 watt |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 0 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.3 in |
| Depth | 8.3 in |
| Height | 1.7 in |
| Weight | 6.94 lbs |
