Hard drive array - 12 bays (SATA-600) 0 - InfiniBand (external) - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Synology DX1215 - hard drive array - TAA Compliant |
| Device Type | Hard drive array |
| Max Supported Capacity | 72 TB |
| Interface | InfiniBand |
| Installed Devices / Modules Qty | 12 (installed) / 12 (max) |
| Supported Drives | SATA-600 |
| Storage Controller | (SATA 6Gb/s) |
| Hard Drive | 0 - hot-swap |
| Power | AC 120/230 V - 50/60 Hz |
| TAA Compliant | Yes |
| Dimensions (WxDxH) | 10.6 in x 11.8 in x 13.4 in |
| Weight | 19.89 lbs |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Hard drive array |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 3.5" |
| Interfaces | 1 x InfiniBand |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Cables Included | 1 x InfiniBand cable |
| Compliant Standards | FCC Class B certified, RoHS, BSMI Class B |
| TAA Compliant | Yes |
| Storage | |
| Max Supported Capacity | 72 TB |
| HDD Array External Interface | InfiniBand |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V - 50/60 Hz |
| Power Provided | 500 watt |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 5 - 95% |
| Sound Emission | 27.2 dBA |
| Storage Controller | |
| Interface Type | SATA 6Gb/s |
| Data Transfer Rate | 600 MBps |
| Hard Drive | |
| Type | Hot-swap |
| Capacity | 0 |
| Dimensions & Weight | |
| Width | 10.6 in |
| Depth | 11.8 in |
| Height | 13.4 in |
| Weight | 19.89 lbs |
| Chassis | |
| Installed Devices / Modules Qty | 12 |
| Supported Devices / Modules Qty | 12 |
| Supported Drives | SATA-600 |
