Graphics card - Radeon R5 230 - 2 GB GDDR3 - PCIe 2.1 x16 low profile - DVI, D-Sub, HDMI - fanless
| Main Specifications | |
|---|---|
| Product Description | MSI R5 230 2GD3H LP - graphics card - Radeon R5 230 - 2 GB |
| Device Type | Graphics card - low profile |
| Bus Type | PCI Express 2.1 x16 |
| Graphics Engine | AMD Radeon R5 230 |
| Memory | 2 GB GDDR3 |
| Core Clock | 625 MHz |
| Effective Memory Clock | 1.066 GHz |
| RAMDAC | 400 MHz |
| Memory Interface | 64-bit |
| Max Resolution | 4096 x 2160 |
| Max Monitors Supported | 2 |
| Interfaces Details | DVI-D (dual link) ¦ HDMI ¦ VGA |
| API Supported | DirectX 11, OpenGL 4.1 |
| Fanless | Yes |
| Dimensions (WxDxH) | 0.7 in x 6.5 in x 2.7 in |
| General | |
| Device Type | Graphics card - low profile - fanless |
| Bus Type | PCI Express 2.1 x16 |
| Graphics Engine | AMD Radeon R5 230 |
| Core Clock | 625 MHz |
| RAMDAC | 400 MHz |
| Max Resolution | 4096 x 2160 at 24 Hz |
| Max Monitors Supported | 2 |
| Interfaces Details | DVI-D (dual link) ¦ HDMI ¦ VGA |
| API Supported | DirectX 11, OpenGL 4.1 |
| Features | MSI Solid Capacitor, MSI Afterburner, HDCP |
| Memory | |
| Size | 2 GB |
| Technology | GDDR3 SDRAM |
| Effective Clock Speed | 1.066 GHz |
| Bus Width | 64-bit |
| Bandwidth | 160 GBps |
| Miscellaneous | |
| Power Consumption Operational | 20 watt |
| Software Included | Drivers & Utilities, Adobe Acrobat Reader, MSI Live Update Series, Microsoft DirectX, MSI Live, MSI Afterburner, MSI StarOSD, MSI Dual Core Center, Norton Internet Security 2008 (60 days trial), MSI Predator |
| Width | 0.7 in |
| Depth | 6.5 in |
| Height | 2.7 in |
| Weight | 6.98 oz |
| System Requirements | |
| Required Power Supply | 400 W |
