Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | D-Link DAP-2660 - wireless access point - Wi-Fi 5 |
| Device Type | Wireless access point |
| Form Factor | External |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac (draft) |
| Frequency Band | 2.4 GHz, 5 GHz |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 6.7 in x 6.7 in x 1.1 in |
| Weight | 11.15 oz |
| General | |
| Device Type | Wireless access point |
| Width | 6.7 in |
| Depth | 6.7 in |
| Height | 1.1 in |
| Weight | 11.15 oz |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous | |
| Compliant Standards | UL, IC, FCC |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1200 Mbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac (draft) |
| Remote Management Protocol | SNMP, Telnet, HTTP, HTTPS, SSH |
| Frequency Band | 2.4 GHz, 5 GHz |
| Status Indicators | Power |
| Features | MAC address filtering, Wireless Distribution System (WDS) support, Quality of Service (QoS), RADIUS support, Network Access Protection (NAP), wireless bridge mode, Wireless Client Mode |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise |
| Authentication Method | RADIUS, Radio Service Set ID (SSID) |
| Compliant Standards | IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.11ac (draft) |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 4 |
