LED monitor - 17" - touchscreen - 1280 x 1024 - 250 cd/m² - DVI, VGA - black
| Main Specifications | |
|---|---|
| Product Description | POS-X ION-TM2B - LED monitor - 17" |
| Device Type | LED-backlit LCD monitor - 17" - touchscreen |
| Features | Touchscreen, USB 2.0 hub |
| Aspect Ratio | 5:4 |
| Native Resolution | 1280 x 1024 |
| Brightness | 250 cd/m² |
| Color Support | 16.7 million colors |
| Input Connectors | DVI, VGA |
| Built-in Ethernet | Yes |
| Display Position Adjustments | Tilt |
| Color | Black |
| Dimensions (WxDxH) | 15.8 in x 11 in x 15 in |
| Weight | 14.77 lbs |
| Compliant Standards | FCC Class A certified, NOM, RoHS, IP54, LVD |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Diagonal Size | 17" |
| Built-in Devices | USB 2.0 hub |
| Aspect Ratio | 5:4 |
| Native Resolution | 1280 x 1024 |
| Brightness | 250 cd/m² |
| Color Support | 16.7 million colors |
| Horizontal Viewing Angle | 160 |
| Vertical Viewing Angle | 160 |
| Backlight Technology | LED backlight |
| Features | 5-Wire Resistive Touch Screen Technology |
| Color | Black |
| Dimensions (WxDxH) | 15.8 in x 11 in x 15 in |
| Weight | 14.77 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Features | Integrated cable management |
| Cables Included | 3 x serial cable |
| Compliant Standards | FCC Class A certified, NOM, RoHS, IP54, LVD |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Connectivity | |
| Interfaces | VGA ¦ DVI ¦ USB 2.0 upstream ¦ USB 2.0 downstream ¦ 2 x serial ¦ Serial (RJ-45) ¦ Serial (DB-9) |
| Input | |
| Type | Touchscreen - touchscreen |
| Movement Detection Technology | Resistive |
| Mechanical | |
| Display Position Adjustments | Tilt |
| Tilt Angle | 90 |
| VESA Mounting Interface | 100 x 100 mm |
