DIN Rail/Wall-Mountable - PoE injector - 24 / 48 V - 30 Watt - black - for P/N: POEEXT1GAT, POEEXT2GAT
| Main Specifications | |
|---|---|
| Product Description | StarTech Industrial 1 Port Gigabit PoE+ Power over Ethernet Injector 48V / 30W with Redundant Power - DIN Rail/Wall-Mountable - PoE injector - 30 Watt |
| Device Type | PoE injector - external |
| Weight | 1.54 lbs |
| Input Voltage | 24 / 48 V |
| Output Voltage | 48 V |
| Power Capacity | 30 Watt |
| Output connectors | 1 x RJ-45 |
| Color | Black |
| Dimensions (WxDxH) | 5.6 in x 4.2 in x 1.5 in |
| Manufacturer Warranty | 2-year warranty |
| Designed For | P/N: POEEXT1GAT, POEEXT2GAT |
| General | |
| Device Type | PoE injector - external |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x Gigabit LAN - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Features | Wall mountable |
| Compliant Standards | EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, FCC, EN 61000-6-2, RoHS, EN 61000-4-8, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IP30 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Power Device | |
| Input Voltage | 24 / 48 V |
| Power Output Connectors Details | 1 x RJ-45 |
| Output Voltage | 48 V |
| Power Capacity | 30 Watt |
| Dimensions & Weight | |
| Width | 5.6 in |
| Depth | 4.2 in |
| Height | 1.5 in |
| Weight | 1.54 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 2.2 lbs |
| Compatibility Information | |
| Designed For | P/N: POEEXT1GAT, POEEXT2GAT |
