Barebone - mini PC Intel NM10 Express - 1 x Atom D2550 - RAM 0 GB - GF GT 610 - Gigabit Ethernet
| Main Specifications | |
|---|---|
| Product Description | ZOTAC ZBOX ID86 - mini PC Atom D2550 1.86 GHz - 0 GB - no HDD |
| Type | PC barebone - mini PC |
| Processor | 1 x Intel Atom D2550 / 1.86 GHz (Dual-Core) |
| Cache Memory | 1 MB L2 cache |
| Cache Per Processor | 1 MB |
| RAM | 0 GB (installed) / 4 GB (max) - DDR3 SDRAM |
| Storage Controller | SATA (SATA 3Gb/s) |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Card Reader | 6 in 1 |
| Graphics Controller | NVIDIA GeForce GT 610 |
| Video Memory | 512 MB DDR3 SDRAM |
| Audio Output | 7.1 channel surround - integrated |
| Networking | 1GbE, 802.11b/g/n, Bluetooth 4.0 |
| OS Provided | No operating system |
| Software Included | Drivers & Utilities |
| Dimensions (WxDxH) | 7.4 in x 7.4 in x 1.7 in |
| Manufacturer Warranty | Limited warranty - 2 years |
| General | |
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 2 (total) / 2 (free) x SO-DIMM 204-pin |
| Interfaces | 1 x DVI (dual link) ¦ 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 ¦ 1 x headphones - mini-jack (1 in front) ¦ 1 x microphone - mini-jack (1 in front) ¦ 2 x USB 3.0 ¦ 1 x SPDIF output |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Vertical stand, wireless antenna, VESA mounting kit |
| Cables Included | DVI-VGA adapter |
| VESA Mounting Interface | Yes |
| RAM | |
| Installed Size | 0 GB (installed) / 4 GB (max) |
| Technology | DDR3 SDRAM |
| Form Factor | SO-DIMM 204-pin |
| Slots | 2 (total) / 2 (empty) |
| Networking | |
| Type | Integrated |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0 |
| Power | |
| Device Type | Power adapter |
| Storage Controller | |
| Type | 1 x SATA - integrated |
| Controller Interface Type | SATA 3Gb/s |
| Cache Memory | |
| Installed Size | L2 cache - 1 MB |
| Cache Per Processor | 1 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Type | Integrated |
| Graphics Processor | NVIDIA GeForce GT 610 |
| Video Memory | 512 MB DDR3 SDRAM |
| Video Interfaces | DVI, HDMI |
| HDCP Compatible | Yes |
| Audio Output | |
| Type | Integrated |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | Drivers & Utilities |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 7.4 in |
| Depth | 7.4 in |
| Height | 1.7 in |
| Card Reader | |
| Type | 6 in 1 card reader |
| Supported Flash Memory Cards | Memory Stick, Memory Stick PRO, MultiMediaCard, SD Memory Card, xD-Picture Card, SDHC Memory Card |
| Processor / Chipset | |
| CPU | Intel Atom D2550 |
| Clock Speed | 1.86 GHz |
| Number of Cores | Dual-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Chipset Type | Intel NM10 Express |
