Network adapter - PCI - 802.11b/g/n
| Main Specifications | |
|---|---|
| Product Description | Startech PCI 300 Mbps Wireless N Network Adapter 802.11n/g 2T2R - network adapter - PCI |
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI |
| Bus Voltage | Universal (3.3 V & 5.0 V) |
| Dimensions (WxDxH) | 0.7 in x 5.1 in x 2.1 in |
| Weight | 1.76 oz |
| Data Link Protocol | 802.11b/g/n |
| Data Transfer Rate | 300 Mbps |
| Frequency Band | 2.4 GHz |
| Processor | Ralink RT3062F |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| System Requirements | Microsoft Windows XP 64-bit Edition, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Linux Kernel 2.6.32, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits), Windows 10 (32/64 bits) |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI |
| Bus Voltage | Universal (3.3 V & 5.0 V) |
| Expansion / Connectivity | |
| Compatible Slots | 1 x PCI |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Low-profile bracket |
| Encryption Algorithm | AES, 128-bit WEP, 64-bit WEP, TKIP, WPA, WPA2 |
| Compliant Standards | FCC, RoHS |
| Networking | |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Data Transfer Rate | 300 Mbps |
| Frequency Band | 2.4 GHz |
| Status Indicators | Link/activity |
| Features | WMM support, QoS, Ad-Hoc Mode, WPS, 2T2R MIMO technology |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows XP 64-bit Edition, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Linux Kernel 2.6.32, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits), Windows 10 (32/64 bits) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 10 - 90% |
| Processor / Memory | |
| Processor | Ralink RT3062F |
| Dimensions & Weight | |
| Width | 0.7 in |
| Depth | 5.1 in |
| Height | 2.1 in |
| Weight | 1.76 oz |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 2 |
| Gain Level | 2 dBi |
