Sound card - 24-bit - 96 kHz - 105 dB SNR - 5.1 - PCIe - CMI-8786 - low profile
| Main Specifications | |
|---|---|
| Product Description | ASUS Xonar DGX - sound card - PCI Express |
| Device Type | Sound card - low profile |
| Enclosure Type | Internal |
| Interface Type | PCI Express |
| Dimensions (WxDxH) | 6.7 in x 2.5 in |
| Signal Processor | CMI-8786 |
| Sound Output Mode | 5.1 channel surround |
| DAC Resolution | 24-bit |
| Sample Rate | 44.1 kHz (min) - 96 kHz (max) |
| Signal-To-Noise Ratio | 105 dB |
| Hardware Controls And Indicators | 10 band EQ |
| General | |
| Device Type | Sound card - low profile |
| Form Factor | Internal |
| Interface Type | PCI Express |
| Depth | 6.7 in |
| Height | 2.5 in |
| Expansion / Connectivity | |
| Interfaces | 1 - mini-phone stereo 3.5 mm ¦ 1 - mini-phone stereo 3.5 mm ¦ 1 - mini-phone 3.5 mm ¦ 1 - mini-phone stereo 3.5 mm ¦ 2 - 4 pin MPC ¦ 1 - TOSLINK |
| Miscellaneous | |
| Included Accessories | Low-profile bracket |
| Software / System Requirements | |
| Software | Drivers & Utilities |
| Audio Output | |
| Sound Output Mode | 5.1 channel surround |
| DAC Resolution | 24-bit |
| Sample Rate | 44.1 kHz (min) - 96 kHz (max) |
| Signal-To-Noise Ratio | 105 dB |
| Frequency Response | 10 - 48000 Hz |
| Hardware Controls And Indicators | 10 band EQ |
| Features | Headphone Amplifier |
| Compliant Standards | DirectSound3D GX 2.5 |
| Processor / Memory | |
| Signal Processor | CMI-8786 |
