Video converter - HD-SDI, 3G-SDI, SD-SDI - HDMI - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Black Box 3G-SDI/HD-SDI to HDMI Converter - video converter - TAA Compliant |
| Device Type | Video converter |
| Interfaces | 1 x HD-SDI - BNC ¦ 1 x HD-SDI output - BNC ¦ 1 x HDMI output - 19 pin HDMI Type A |
| Dimensions (WxDxH) | 3.3 in x 3.1 in x 1.1 in |
| TAA Compliant | Yes |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Video converter |
| Interfaces | 1 x HD-SDI - BNC ¦ 1 x HD-SDI output - BNC ¦ 1 x HDMI output - 19 pin HDMI Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Power Consumption Operational | 3 Watt |
| Compliant Standards | RoHS |
| Width | 3.3 in |
| Depth | 3.1 in |
| Height | 1.1 in |
| Weight | 8.82 oz |
| TAA Compliant | Yes |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| System Requirements | |
| Voltage Required | AC 100/230 V (50 - 60 Hz) |
| Video Input | |
| Analog Video Format | NTSC, PAL |
